KHAL 41

41x41 mm profile rail, perforated

The mounting channel KHAL 41 consists of a C+ profile 41 x 41 mm with continuous perforation and a slot width of 22 mm made from material 1.5 mm thick. We provide components in various materials and surface finishes to ensure that the corrosion requirements are met for all sorts of applications. KHAL 41 also serves as a bracket holder in combination with the BGA 41 head plate and is available in lengths of up to 6000 mm.

Get in touch Download datasheet

Variants

Article

steel, continously hot galvanized/Sendzimir process

Article

H

B

L

t

W

  • KHAL 41-30S
    Bracket support KHAL 41-30S
    41 mm
    41 mm
    3000 mm
    1.50 mm
    4.680 kg
    More information
  • KHAL 41-60S
    Bracket support KHAL 41-60S
    41 mm
    41 mm
    6000 mm
    1.50 mm
    9.360 kg
    More information

steel, batch/hot-dip galvanized

Article

H

B

L

t

W

  • KHAL 41-05F
    KHA-profile KHAL 41-05F
    41 mm
    41 mm
    500 mm
    1.50 mm
    0.834 kg
    More information
  • KHAL 41-10F
    KHA-profile KHAL 41-10F
    41 mm
    41 mm
    1000 mm
    1.50 mm
    1.669 kg
    More information
  • KHAL 41-15F
    KHA-profile KHAL 41-15F
    41 mm
    41 mm
    1500 mm
    1.50 mm
    2.503 kg
    More information
  • KHAL 41-20F
    KHA-profile KHAL 41-20F
    41 mm
    41 mm
    2000 mm
    1.50 mm
    3.337 kg
    More information
  • KHAL 41-30F
    KHA-profile KHAL 41-30F
    41 mm
    41 mm
    3000 mm
    1.50 mm
    5.006 kg
    More information
  • KHAL 41-60F
    KHA-profile KHAL 41-60F
    41 mm
    41 mm
    6000 mm
    1.50 mm
    10.012 kg
    More information
