SKS A

Clamping claw, heavy, A/KHA 21/41/42/82

The beam clamp set SKS A can be combined with mounting channels A 41 or KHA 21, 41, 42 and 82. It is used to attach bracket supports on steel beams. The set can be loaded up to 20 kN. The clamping range extends from 10 - 30 mm. We provide components in various materials and surface finishes to ensure that various corrosion protection requirements for different areas of application are met.

Get in touch Download datasheet

Variants

Steel, hot-dip galvanised

SKS AF
Beam clamps SKS AF

maximum load

20.00 kN

torque

50 Nm

clamping range

10 - 30 mm

Weight per storage unit

0.555 kg

Included accessories

More information

Stainless steel, according to ASTM 316 Ti / AISI 316 L, BS 320S17 / BS 316S11

SKS AE4
Beam clamps SKS AE4

maximum load

20.00 kN

torque

50 Nm

clamping range

10 - 30 mm

Weight per storage unit

0.552 kg

Included accessories

More information

Tender texts

Ausschreiben.de

Tender text for this product

Open Link

Heinze.de

Tender text for this product

Open Link

Accessories

Downloads

Price list Building extension 2025

Valid from February 1st, 2025, updated version from 27/01/2025.

PDF, 46 MB

de en
Safe working load (SKS)

Certificate, tested in accordance to DIN EN ISO 6892-1

PDF, 259 KB

de en

BIM- and CAD-Data

BIM Data Cablele Support System Fastening Accessories (Revit)

BIM Data

ZIP, 39 MB

de en
