AV 41

Connector, A/KHA 21/41/42/82

The connector AV 41 can be used to connect mounting channels A or KHA 21/41/42/82 together end to end. It is made of hot-dip galvanised steel.

Get in touchDownload datasheet

Variants

Stahl, stück-/tauchfeuerverzinkt

Article

H

Höhe

B

Breite

L

Länge

t

Materialstärke

G

Gewicht je Lagermengeneinheit

  • AV 41F
    Profilschienenverbinder
    Höhe
    50 mm
    Breite
    40 mm
    Länge
    200 mm
    Materialstärke
    4.00 mm
    Gewicht je Lagermengeneinheit
    0.723 kg
    More information

Tender texts

Ausschreiben.de

Tender text for this product

Open Link
Heinze.de

Tender text for this product

Open Link

Downloads

    Support systems Assembling instruction

    • de

    • en

    Support systems - Technical information

    Technical information

    • de

    • en

Included accessories
