KA 30

Bracket, light

The strut bracket KA 30 is attached to bracket holder KDAG 41 or KHA 41/KHAL 41 and is intended for loads up to 0.5 kN. The system is ideal for suspending mesh cable trays and cable trays up to 400 mm wide. The bracket is made of hot-dip galvanised steel.

Get in touchDownload datasheet

Variants

Steel, hot-dip galvanised

Article

H

height

B

width

B1

width 1

L

length

Pmax

maximum load

G

Weight per storage unit

Geeignet für Funktionserhalt

  • KA 30-010F
    Bracket KA 30-010F
    height
    95 mm
    width
    125 mm
    width 1
    100 mm
    length
    40 mm
    maximum load
    0.50 kN
    Weight per storage unit
    0.250 kg
    Geeignet für Funktionserhalt
    Nein
    More information
  • KA 30-015F
    Bracket KA 30-015F
    height
    95 mm
    width
    175 mm
    width 1
    150 mm
    length
    40 mm
    maximum load
    0.50 kN
    Weight per storage unit
    0.290 kg
    Geeignet für Funktionserhalt
    Nein
    More information
  • KA 30-020F
    Bracket KA 30-020F
    height
    95 mm
    width
    225 mm
    width 1
    200 mm
    length
    40 mm
    maximum load
    0.50 kN
    Weight per storage unit
    0.330 kg
    Geeignet für Funktionserhalt
    Nein
    More information
  • KA 30-025F
    Bracket KA 30-025F
    height
    95 mm
    width
    275 mm
    width 1
    250 mm
    length
    40 mm
    maximum load
    0.50 kN
    Weight per storage unit
    0.360 kg
    Geeignet für Funktionserhalt
    Nein
    More information
  • KA 30-030F
    Bracket KA 30-030F
    height
    95 mm
    width
    325 mm
    width 1
    300 mm
    length
    40 mm
    maximum load
    0.50 kN
    Weight per storage unit
    0.400 kg
    Geeignet für Funktionserhalt
    Nein
    More information
  • KA 30-040F
    Bracket KA 30-040F
    height
    95 mm
    width
    425 mm
    width 1
    400 mm
    length
    40 mm
    maximum load
    0.50 kN
    Weight per storage unit
    0.470 kg
    Geeignet für Funktionserhalt
    Nein
    More information
