KHA 41

41x41 mm profile rail, perforated, maintenance of function

Fire protection
Get in touchDownload datasheet

Variants

Steel, hot-dip galvanised

Article

H

height

B

width

L

length

t

material thickness

G

Weight per storage unit

  • KHA 41-01F
    Profile rail perforated 41/41x2,5
    height
    41 mm
    width
    41 mm
    length
    100 mm
    material thickness
    2.50 mm
    Weight per storage unit
    0.260 kg
    More information
  • KHA 41-02F
    Profile rail perforated 41/41x2,5
    height
    41 mm
    width
    41 mm
    length
    200 mm
    material thickness
    2.50 mm
    Weight per storage unit
    0.500 kg
    More information
  • KHA 41-03F
    Profile rail perforated 41/41x2,5
    height
    41 mm
    width
    41 mm
    length
    300 mm
    material thickness
    2.50 mm
    Weight per storage unit
    0.700 kg
    More information
  • KHA 41-04F
    Profile rail perforated 41/41x2,5
    height
    41 mm
    width
    41 mm
    length
    400 mm
    material thickness
    2.50 mm
    Weight per storage unit
    1.000 kg
    More information
  • KHA 41-05F
    Profile rail perforated 41/41x2,5
    height
    41 mm
    width
    41 mm
    length
    500 mm
    material thickness
    2.50 mm
    Weight per storage unit
    1.300 kg
    More information

Details

    Tender texts

    Ausschreiben.de

    Tender texts for this product

    Open Link
    Heinze.de

    Tender texts for this product

    Open Link

    Included accessories
