KHA 21

41x21 mm profile rail, perforated

The mounting channel KHA 21 consists of a C+ profile 41 x 21 mm with continuous perforation and a slot width of 22 mm made from material 2.5 mm thick. We provide components in various materials and surface finishes to ensure that the corrosion requirements are met for all sorts of applications. It is available in lengths of up to 6000 mm.

Get in touch Download datasheet

Variants

steel, batch/hot-dip galvanized

Article

H

B

L

t

W

  • KHA 21-30F
    bracket support KHA 21-30F
    21 mm
    41 mm
    3000 mm
    2.50 mm
    5.320 kg
    More information
  • KHA 21-60F
    bracket support KHA 21-60F
    21 mm
    41 mm
    6000 mm
    2.50 mm
    10.639 kg
    More information

Stainless steel, according to ASTM 316 Ti / AISI 316 L, BS 320S17 / BS 316S11

Article

H

B

L

t

W

  • KHA 21-30E4
    bracket support KHA 21-30E4
    21 mm
    41 mm
    3000 mm
    2.50 mm
    4.970 kg
    More information
  • KHA 21-60E4
    bracket support KHA 21-60E4
    21 mm
    41 mm
    6000 mm
    2.50 mm
    9.943 kg
    More information
