R 60

Cable tray, unperforated, height = 60 mm

The unperforated cable trays R 60 have sides 60 mm high and are available in widths from 50 to 600 mm. The standard length is 3000 mm. We provide components in various materials and surface finishes to ensure that the corrosion requirements are met for all sorts of applications.

The magnetic shielding attenuation is 22 dB without the cover and 30 dB with the cover.

No stepping

Get in touch Download datasheet

Variants

Steel, pre-galvanised/Sendzimir process

R 60-05S
Cable tray, unperforated
height
60 mm
width
50 mm
length
3000 mm
material thickness
0.75 mm
distributed load control cable
0.04 kN/m
cross section area
27 cm²
Weight per storage unit
3.730 kg
More information
R 60-10S
Cable tray, unperforated R 60-10S
height
60 mm
width
100 mm
length
3000 mm
material thickness
0.75 mm
distributed load control cable
0.09 kN/m
cross section area
57 cm²
Weight per storage unit
4.601 kg
More information
R 60-20S
Cable tray, unperforated R 60-20S
height
60 mm
width
200 mm
length
3000 mm
material thickness
0.75 mm
distributed load control cable
0.17 kN/m
cross section area
117 cm²
Weight per storage unit
6.368 kg
More information
R 60-30S
Cable tray, unperforated R 60-30S
height
60 mm
width
300 mm
length
3000 mm
material thickness
0.75 mm
distributed load control cable
0.26 kN/m
cross section area
177 cm²
Weight per storage unit
8.134 kg
More information
R 60-40S
Cable tray, unperforated R 60-40S
height
60 mm
width
400 mm
length
3000 mm
material thickness
0.88 mm
distributed load control cable
0.34 kN/m
cross section area
237 cm²
Weight per storage unit
11.595 kg
More information
R 60-50S
Cable tray, unperforated R 60-50S
height
60 mm
width
500 mm
length
3000 mm
material thickness
1.00 mm
distributed load control cable
0.43 kN/m
cross section area
297 cm²
Weight per storage unit
15.508 kg
More information
R 60-60S
Cable tray, unperforated R 60-60S
height
60 mm
width
600 mm
length
3000 mm
material thickness
1.00 mm
distributed load control cable
0.52 kN/m
cross section area
357 cm²
Weight per storage unit
17.863 kg
More information

Steel, hot-dip galvanised

R 60-05F
Cable tray, unperforated
height
60 mm
width
50 mm
length
3000 mm
material thickness
0.75 mm
distributed load control cable
0.04 kN/m
cross section area
27 cm²
Weight per storage unit
4.180 kg
More information
R 60-10F
Cable tray, unperforated R 60-10F
height
60 mm
width
100 mm
length
3000 mm
material thickness
0.75 mm
distributed load control cable
0.09 kN/m
cross section area
57 cm²
Weight per storage unit
5.159 kg
More information
R 60-20F
Cable tray, unperforated R 60-20F
height
60 mm
width
200 mm
length
3000 mm
material thickness
0.75 mm
distributed load control cable
0.17 kN/m
cross section area
117 cm²
Weight per storage unit
7.139 kg
More information
R 60-30F
Cable tray, unperforated R 60-30F
height
60 mm
width
300 mm
length
3000 mm
material thickness
0.75 mm
distributed load control cable
0.26 kN/m
cross section area
177 cm²
Weight per storage unit
9.119 kg
More information
R 60-40F
Cable tray, unperforated R 60-40F
height
60 mm
width
400 mm
length
3000 mm
material thickness
0.88 mm
distributed load control cable
0.34 kN/m
cross section area
237 cm²
Weight per storage unit
12.793 kg
More information
R 60-50F
Cable tray, unperforated R 60-50F
height
60 mm
width
500 mm
length
3000 mm
material thickness
1.00 mm
distributed load control cable
0.43 kN/m
cross section area
297 cm²
Weight per storage unit
16.917 kg
More information
R 60-60F
Cable tray, unperforated R 60-60F
height
60 mm
width
600 mm
length
3000 mm
material thickness
1.00 mm
distributed load control cable
0.52 kN/m
cross section area
357 cm²
Weight per storage unit
19.486 kg
More information

Stainless steel, acc. to AISI 304 (BS 304S31)

R 60-05E
Cable tray, unperforated
height
60 mm
width
50 mm
length
3000 mm
material thickness
0.80 mm
distributed load control cable
0.04 kN/m
cross section area
27 cm²
Weight per storage unit
4.000 kg
More information
R 60-10E
Cable tray, unperforated R 60-10E
height
60 mm
width
100 mm
length
3000 mm
material thickness
0.80 mm
distributed load control cable
0.09 kN/m
cross section area
57 cm²
Weight per storage unit
4.900 kg
More information
R 60-20E
Cable tray, unperforated R 60-20E
height
60 mm
width
200 mm
length
3000 mm
material thickness
0.80 mm
distributed load control cable
0.17 kN/m
cross section area
117 cm²
Weight per storage unit
6.800 kg
More information
R 60-30E
Cable tray, unperforated R 60-30E
height
60 mm
width
300 mm
length
3000 mm
material thickness
0.80 mm
distributed load control cable
0.26 kN/m
cross section area
177 cm²
Weight per storage unit
8.800 kg
More information
R 60-40E
Cable tray, unperforated R 60-40E
height
60 mm
width
400 mm
length
3000 mm
material thickness
0.80 mm
distributed load control cable
0.34 kN/m
cross section area
237 cm²
Weight per storage unit
10.600 kg
More information
R 60-50E
Cable tray, unperforated R 60-50E
height
60 mm
width
500 mm
length
3000 mm
material thickness
1.00 mm
distributed load control cable
0.43 kN/m
cross section area
297 cm²
Weight per storage unit
15.600 kg
More information
R 60-60E
Cable tray, unperforated R 60-60E
height
60 mm
width
600 mm
length
3000 mm
material thickness
1.00 mm
distributed load control cable
0.52 kN/m
cross section area
357 cm²
Weight per storage unit
17.900 kg
More information

Stainless steel, acc. to AISI 316Ti (BS 320S31) / AISI 316L (BS 316S11)

R 60-10E4
Cable tray
height
60 mm
width
100 mm
length
3000 mm
material thickness
0.80 mm
distributed load control cable
0.09 kN/m
cross section area
57 cm²
Weight per storage unit
5.002 kg
More information
R 60-20E4
Cable tray, unperforated
height
60 mm
width
200 mm
length
3000 mm
material thickness
0.80 mm
distributed load control cable
0.17 kN/m
cross section area
117 cm²
Weight per storage unit
6.835 kg
More information
R 60-30E4
Cable tray, unperforated
height
60 mm
width
300 mm
length
3000 mm
material thickness
0.80 mm
distributed load control cable
0.26 kN/m
cross section area
177 cm²
Weight per storage unit
8.731 kg
More information
R 60-40E4
Cable tray
height
60 mm
width
400 mm
length
3000 mm
material thickness
0.80 mm
distributed load control cable
0.34 kN/m
cross section area
237 cm²
Weight per storage unit
10.790 kg
More information
R 60-50E4
Cable tray
height
60 mm
width
500 mm
length
3000 mm
material thickness
1.00 mm
distributed load control cable
0.43 kN/m
cross section area
297 cm²
Weight per storage unit
15.840 kg
More information
R 60-60E4
Cable tray
height
60 mm
width
600 mm
length
3000 mm
material thickness
1.00 mm
distributed load control cable
0.52 kN/m
cross section area
357 cm²
Weight per storage unit
20.568 kg
More information

Details

No stepping
Electr. conductivity checked according to DIN EN 61537

Tender texts

Ausschreiben.de

Tender texts for this product

Open Link

Heinze.de

Tender texts for this product

Open Link

Accessories

Downloads

**Price list 2025 Building extension**
Valid from February 1st, 2025, updated version from 31/03/2025.
de
en

**Cable trays - Technical information**
Technical Information
de
en

**Cable support systems - Complete catalogue**
Catalogue for cable trays, mesh cable trays, cable ladders, wide-span systems, vertical ladders, floor ducts, cable clamps, cable support troughs, rigid conduits, marine cable ladders, support systems, fastening accessories and more.
de
en

**Cable trays - Assembly instructions**
Assembly Instructions
de
en

**Cable Tray R 60, RG 60 - Compact overview**
Compact overview of cable trays and accessories: R, RG, RGV, VB, RTR, DB, DKSL, KDU, KHUSS, GBAR, KWF, MA, KWMS, RD, RKAB, RTRV, RBV, RVB, REB
PDF, 1.12 MB
de
Download

**VDE Certificate 329860-TL7-1 Cable management systems**
Certificate for Grid track G 50-30, G 50-40; Cable tray RG 60-30, RGS 60-30, R 60-30; Cable ladder LGG 60-30; Wide-span cable trays WPR 120-30; Wide-span cable ladders WLR 200-30, WPL 150-30
de
en

BIM- und CAD-Data

BIM for cable trays

Bim data

Load diagram
