RTR 60

Cable tray divider, height = 50 mm

Cables and lines with different functions or voltages can be routed separately from one another in the same cable tray using the cable tray separating strip RTR 60. The separating strip is bolted to the cable tray three times or fastened with KLF approx. 100 mm away from both ends of the separating strip and in the middle. The cable tray separating strip is 50 mm high and 3000 mm long. We provide components in various materials and surface finishes to ensure that the corrosion requirements are met for all sorts of applications.

Get in touch Download datasheet

Variants

Steel, pre-galvanised/Sendzimir process

Article

H

height

L

length

G

Weight per storage unit
  • RTR 60S
    Cable tray barrier strip RTR 60S
    height
    50 mm
    length
    3000 mm
    Weight per storage unit
    1.528 kg
    Included accessories
    More information

Steel, hot-dip galvanised

Article

H

height

L

length

G

Weight per storage unit
  • RTR 60F
    Cable tray barrier strip RTR 60F
    height
    50 mm
    length
    3000 mm
    Weight per storage unit
    1.634 kg
    Included accessories
    More information

Stainless steel, acc. to AISI 304 (BS 304S31)

Article

H

height

L

length

G

Weight per storage unit
  • RTR 60E
    Cable tray barrier strip RTR 60E
    height
    50 mm
    length
    3000 mm
    Weight per storage unit
    2.046 kg
    Included accessories
    More information

Stainless steel, acc. to AISI 316Ti (BS 320S31) / AISI 316L (BS 316S11)

Article

H

height

L

length

G

Weight per storage unit
  • RTR 60E4
    Seperating strip for cable tray
    height
    50 mm
    length
    3000 mm
    Weight per storage unit
    2.074 kg
    Included accessories
    More information
