REB

Cable tray end plate

The cable tray end plate REB is inserted and bolted into the bottom of the cable tray if the cable tray ends are open and protects cables that are fed in or out. However, it can also be used as a spacer according to the installation instructions wherever the direction changes horizontally or vertically. We provide components in various materials and surface finishes to ensure that the corrosion requirements are met for all sorts of applications.

Get in touch Download datasheet

Variants

Steel, pre-galvanised/Sendzimir process

Article

H

height

B

width

L

length

G

Weight per storage unit
  • REB 05S
    Cable tray end-plate REB 05S
    height
    6 mm
    width
    40 mm
    length
    87 mm
    Weight per storage unit
    0.043 kg
    Included accessories
    More information
  • REB 10S
    Cable tray end-plate REB 10S
    height
    6 mm
    width
    95 mm
    length
    50 mm
    Weight per storage unit
    0.043 kg
    Included accessories
    More information
  • REB 15S
    Cable tray end-plate REB 15S
    height
    6 mm
    width
    140 mm
    length
    50 mm
    Weight per storage unit
    0.059 kg
    Included accessories
    More information
  • REB 20S
    Cable tray end-plate REB 20S
    height
    6 mm
    width
    190 mm
    length
    50 mm
    Weight per storage unit
    0.075 kg
    Included accessories
    More information
  • REB 30S
    Cable tray end-plate REB 30S
    height
    6 mm
    width
    290 mm
    length
    50 mm
    Weight per storage unit
    0.110 kg
    Included accessories
    More information
  • REB 40S
    Cable tray end-plate REB 40S
    height
    6 mm
    width
    390 mm
    length
    50 mm
    Weight per storage unit
    0.146 kg
    Included accessories
    More information
  • REB 50S
    Cable tray end-plate REB 50S
    height
    6 mm
    width
    490 mm
    length
    50 mm
    Weight per storage unit
    0.181 kg
    Included accessories
    More information
  • REB 60S
    Cable tray end-plate REB 60S
    height
    6 mm
    width
    590 mm
    length
    50 mm
    Weight per storage unit
    0.216 kg
    Included accessories
    More information

Steel, hot-dip galvanised

Article

H

height

B

width

L

length

G

Weight per storage unit
  • REB 05F
    Cable tray end-plate REB 05F
    height
    6 mm
    width
    40 mm
    length
    87 mm
    Weight per storage unit
    0.047 kg
    Included accessories
    More information
  • REB 10F
    Cable tray end-plate REB 10F
    height
    6 mm
    width
    95 mm
    length
    50 mm
    Weight per storage unit
    0.047 kg
    Included accessories
    More information
  • REB 15F
    Cable tray end-plate REB 15F
    height
    6 mm
    width
    140 mm
    length
    50 mm
    Weight per storage unit
    0.064 kg
    Included accessories
    More information
  • REB 20F
    Cable tray end-plate REB 20F
    height
    6 mm
    width
    190 mm
    length
    50 mm
    Weight per storage unit
    0.081 kg
    Included accessories
    More information
  • REB 30F
    Cable tray end-plate REB 30F
    height
    6 mm
    width
    290 mm
    length
    50 mm
    Weight per storage unit
    0.119 kg
    Included accessories
    More information
  • REB 40F
    Cable tray end-plate REB 40F
    height
    6 mm
    width
    390 mm
    length
    50 mm
    Weight per storage unit
    0.157 kg
    Included accessories
    More information
  • REB 50F
    Cable tray end-plate REB 50F
    height
    6 mm
    width
    490 mm
    length
    50 mm
    Weight per storage unit
    0.194 kg
    Included accessories
    More information
  • REB 60F
    Cable tray end-plate REB 60F
    height
    6 mm
    width
    590 mm
    length
    50 mm
    Weight per storage unit
    0.232 kg
    Included accessories
    More information

Stainless steel, according to ASTM 304 / BS 304 S 3

Article

H

height

B

width

L

length

G

Weight per storage unit
  • REB 10E
    Cable tray end-plate REB 10E
    height
    6 mm
    width
    95 mm
    length
    50 mm
    Weight per storage unit
    0.047 kg
    Included accessories
    More information
  • REB 20E
    Cable tray end-plate REB 20E
    height
    6 mm
    width
    190 mm
    length
    50 mm
    Weight per storage unit
    0.081 kg
    Included accessories
    More information
  • REB 30E
    Cable tray end-plate REB 30E
    height
    6 mm
    width
    290 mm
    length
    50 mm
    Weight per storage unit
    0.120 kg
    Included accessories
    More information
  • REB 40E
    Cable tray end-plate REB 40E
    height
    6 mm
    width
    390 mm
    length
    50 mm
    Weight per storage unit
    0.156 kg
    Included accessories
    More information
  • REB 50E
    Cable tray end-plate REB 50E
    height
    6 mm
    width
    490 mm
    length
    50 mm
    Weight per storage unit
    0.195 kg
    Included accessories
    More information
  • REB 60E
    Cable tray end-plate REB 60E
    height
    6 mm
    width
    590 mm
    length
    50 mm
    Weight per storage unit
    0.233 kg
    Included accessories
    More information

Stainless steel, according to ASTM 316 Ti / AISI 316 L, BS 320S17 / BS 316S11

Article

H

height

B

width

L

length

G

Weight per storage unit
  • REB 10E4
    Cable tray end-plate REB 10E
    height
    6 mm
    width
    95 mm
    length
    50 mm
    Weight per storage unit
    0.049 kg
    Included accessories
    More information
  • REB 20E4
    Cable tray end-plate REB 20E
    height
    6 mm
    width
    190 mm
    length
    50 mm
    Weight per storage unit
    0.083 kg
    Included accessories
    More information
  • REB 30E4
    Cable tray end-plate REB 30E
    height
    6 mm
    width
    290 mm
    length
    50 mm
    Weight per storage unit
    0.122 kg
    Included accessories
    More information
  • REB 40E4
    Cable tray end-plate REB 40E
    height
    6 mm
    width
    390 mm
    length
    50 mm
    Weight per storage unit
    0.158 kg
    Included accessories
    More information
  • REB 50E4
    Cable tray end-plate REB 50E
    height
    6 mm
    width
    490 mm
    length
    50 mm
    Weight per storage unit
    0.197 kg
    Included accessories
    More information
  • REB 60E4
    Cable tray end-plate REB 60E
    height
    6 mm
    width
    590 mm
    length
    50 mm
    Weight per storage unit
    0.235 kg
    Included accessories
    More information
