WPL 100

Wide-span cable ladder, height = 100 mm

The wide-span cable ladders WPL 100 have rails 100 mm high and are available in widths of 200 to 600 mm. The standard length is 6000 mm. The rungs consist of perforated profile rails. The wide-span spar supports are to be used for fastening to the substructure. We provide components in various materials and surface finishes to ensure that the corrosion requirements are met for all sorts of applications.

Betreten verboten
Get in touch Download datasheet

Variants

Stainless steel, according to ASTM 304 / BS 304 S 3

Article

H

HH

B

L

t

QLK

A

W

  • WPL 100-20E
    Wide-span cable ladder WPL 100-20E
    100 mm
    100 mm
    200 mm
    6000 mm
    1.50 mm
    0.44 kN/m
    156 cm2
    24.750 kg
    More information
  • WPL 100-30E
    Wide-span cable ladder WPL 100-30E
    100 mm
    100 mm
    300 mm
    6000 mm
    1.50 mm
    0.66 kN/m
    234 cm2
    26.130 kg
    More information
  • WPL 100-40E
    Wide-span cable ladder WPL 100-40E
    100 mm
    100 mm
    400 mm
    6000 mm
    1.50 mm
    0.87 kN/m
    312 cm2
    27.510 kg
    More information
  • WPL 100-50E
    Wide-span cable ladder WPL 100-50E
    100 mm
    100 mm
    500 mm
    6000 mm
    1.50 mm
    1.09 kN/m
    390 cm2
    28.890 kg
    More information
  • WPL 100-60E
    Wide-span cable ladder WPL 100-60E
    100 mm
    100 mm
    600 mm
    6000 mm
    1.50 mm
    1.31 kN/m
    468 cm2
    30.270 kg
    More information

Stainless steel, according to ASTM 316 Ti / AISI 316 L, BS 320S17 / BS 316S11

Article

H

HH

B

L

t

QLK

A

W

  • WPL 100-20E4
    Wide-span cable ladder WPL 100-20E4
    100 mm
    100 mm
    200 mm
    6000 mm
    1.50 mm
    0.44 kN/m
    156 cm2
    25.060 kg
    More information
  • WPL 100-30E4
    Wide-span cable ladder WPL 100-30E4
    100 mm
    100 mm
    300 mm
    6000 mm
    1.50 mm
    0.66 kN/m
    234 cm2
    26.460 kg
    More information
  • WPL 100-40E4
    Wide-span cable ladder WPL 100-40E4
    100 mm
    100 mm
    400 mm
    6000 mm
    1.50 mm
    0.87 kN/m
    312 cm2
    27.860 kg
    More information
  • WPL 100-50E4
    Wide-span cable ladder WPL 100-50E4
    100 mm
    100 mm
    500 mm
    6000 mm
    1.50 mm
    1.09 kN/m
    390 cm2
    29.260 kg
    More information
  • WPL 100-60E4
    Wide-span cable ladder WPL 100-60E4
    100 mm
    100 mm
    600 mm
    6000 mm
    1.50 mm
    1.31 kN/m
    468 cm2
    30.650 kg
    More information

Details

  • Betreten verboten

Tender texts

Ausschreiben.de

Tender text for this product

Open Link
Heinze.de

Tender text for this product

Open Link

Accessories

Downloads

  • Price list Building extension 2025

    Valid from February 1st, 2025, updated version from 27/01/2025.

    PDF, 46 MB

    de en

  • Rote Mappe - Funktionserhalt Tragkonstruktion DIN 4102-12

    Gesamtkatalog

    PDF, 29 MB

    de
    Download

  • BK Bodenkanal - Technische Information

    Montageanleitung

    PDF, 2 MB

    de
    Download

  • Test Report RAPIDOBAT® Cretcon HD

    Technische Information

    PDF, 4 MB

    de en

  • Weitspannkabelrinne WPR 100, 120, 150

    Kompaktübersicht

    PDF, 1 MB

    de
    Download

  • Electrical conductivity (WP/WPL 100)

    Certificate, tested according to DIN EN 61537 Pt. 11.1

    PDF, 263 KB

    de en

Load diagram
