RG 85

Cable tray, perforated, height = 85 mm

The RG 85 perforated cable trays have sides 85 mm high and are available in widths from 100 to 600 mm. The standard length is 3000 mm. We provide components in various materials and surface finishes to ensure that the corrosion requirements are met for all sorts of applications.

No stepping
Get in touchDownload datasheet

Variants

Steel, pre-galvanised/Sendzimir process

Article

H

height

B

width

L

length

t

material thickness

QSK

distributed load control cable

A

cross section area

G

Weight per storage unit

  • RG 85-10S
    Cable tray RG 85-10S
    height
    85 mm
    width
    100 mm
    length
    3000 mm
    material thickness
    0.75 mm
    distributed load control cable
    0.12 kN/m
    cross section area
    82 cm2
    Weight per storage unit
    5.010 kg
    More information
  • RG 85-20S
    Cable tray RG 85-20S
    height
    85 mm
    width
    200 mm
    length
    3000 mm
    material thickness
    0.75 mm
    distributed load control cable
    0.25 kN/m
    cross section area
    167 cm2
    Weight per storage unit
    6.500 kg
    More information
  • RG 85-30S
    Cable tray RG 85-30S
    height
    85 mm
    width
    300 mm
    length
    3000 mm
    material thickness
    0.88 mm
    distributed load control cable
    0.38 kN/m
    cross section area
    252 cm2
    Weight per storage unit
    9.600 kg
    More information
  • RG 85-40S
    Cable tray RG 85-40S
    height
    85 mm
    width
    400 mm
    length
    3000 mm
    material thickness
    0.88 mm
    distributed load control cable
    0.51 kN/m
    cross section area
    337 cm2
    Weight per storage unit
    11.600 kg
    More information
  • RG 85-50S
    Cable tray RG 85-50S
    height
    85 mm
    width
    500 mm
    length
    3000 mm
    material thickness
    1.00 mm
    distributed load control cable
    0.63 kN/m
    cross section area
    422 cm2
    Weight per storage unit
    15.250 kg
    More information
  • RG 85-60S
    Cable tray RG 85-60S
    height
    85 mm
    width
    600 mm
    length
    3000 mm
    material thickness
    1.00 mm
    distributed load control cable
    0.76 kN/m
    cross section area
    507 cm2
    Weight per storage unit
    17.600 kg
    More information

Steel, hot-dip galvanised

Article

H

height

B

width

L

length

t

material thickness

QSK

distributed load control cable

A

cross section area

G

Weight per storage unit

  • RG 85-10F
    Cable tray RG 85-10F
    height
    85 mm
    width
    100 mm
    length
    3000 mm
    material thickness
    0.75 mm
    distributed load control cable
    0.12 kN/m
    cross section area
    82 cm2
    Weight per storage unit
    6.000 kg
    More information
  • RG 85-20F
    Cable tray RG 85-20F
    height
    85 mm
    width
    200 mm
    length
    3000 mm
    material thickness
    0.75 mm
    distributed load control cable
    0.25 kN/m
    cross section area
    167 cm2
    Weight per storage unit
    7.150 kg
    More information
  • RG 85-30F
    Cable tray RG 85-30F
    height
    85 mm
    width
    300 mm
    length
    3000 mm
    material thickness
    0.88 mm
    distributed load control cable
    0.38 kN/m
    cross section area
    252 cm2
    Weight per storage unit
    10.550 kg
    More information
  • RG 85-40F
    Cable tray RG 85-40F
    height
    85 mm
    width
    400 mm
    length
    3000 mm
    material thickness
    0.88 mm
    distributed load control cable
    0.51 kN/m
    cross section area
    337 cm2
    Weight per storage unit
    12.900 kg
    More information
  • RG 85-50F
    Cable tray RG 85-50F
    height
    85 mm
    width
    500 mm
    length
    3000 mm
    material thickness
    1.00 mm
    distributed load control cable
    0.63 kN/m
    cross section area
    422 cm2
    Weight per storage unit
    16.600 kg
    More information
  • RG 85-60F
    Cable tray RG 85-60F
    height
    85 mm
    width
    600 mm
    length
    3000 mm
    material thickness
    1.00 mm
    distributed load control cable
    0.76 kN/m
    cross section area
    507 cm2
    Weight per storage unit
    18.400 kg
    More information

Details

  • No stepping
  • Electr. conductivity checked according to DIN EN 61537

Tender texts

Ausschreiben.de

Tender texts for this product

Open Link
Heinze.de

Tender texts for this product

Open Link

Accessories

Downloads

    Price list 2025 Building extension

    Valid from February 1st, 2025, updated version from 31/03/2025.

    • de

    • en

    Cable trays - Technical information

    Technical Information

    • de

    • en

    Cable support systems - Complete catalogue

    Catalogue for cable trays, mesh cable trays, cable ladders, wide-span systems, vertical ladders, floor ducts, cable clamps, cable support troughs, rigid conduits, marine cable ladders, support systems, fastening accessories and more.

    • de

    • en

    Cable trays - Assembly instructions

    Assembly Instructions

    • de

    • en

    Cable Tray R 60, RG 60 - Compact overview

    Compact overview of cable trays and accessories: R, RG, RGV, VB, RTR, DB, DKSL, KDU, KHUSS, GBAR, KWF, MA, KWMS, RD, RKAB, RTRV, RBV, RVB, REB

    PDF, 1.12 MB

    • de

    Download

    Electrical conductivity (RG 35/60 and RI 60)

    Certificate, tested according to DIN EN 61537 Pt. 11.1

    • de

    • en

    Safe working load (RG 85)

    Certificate, tested in accordance to DIN EN 61537

    • de

    • en

BIM- und CAD-Data

    BIM for cable trays

    Bim data

    • de

    • en

Load diagram
