JB M10

Hook-head t-bolt

JB M10 have European Technical Assessment ETA-09/0338. They are used to fasten companion structures to W 55/42, W 53/34, K 53/34, W 50+, K 50/40, W 50/30, K 50/30 and K 48/26 anchor channels and mounting channels. The bolts have hooked heads and a notch at the end of the shaft. They are made of hot-dip galvanised steel, galvanised steel or stainless steel. The JB M10 are available in different lengths. The nuts are included.

Fire protection
European Technical Assessment: ETA-09/0338

Variants

Stahl, stück-/tauchfeuerverzinkt

Article

L

Länge

Festigkeitsklasse

MG

Gewindemaß (metrisch)

G

Gewicht je Lagermengeneinheit

  • JB1080 FV
    JORDAHL Schraube JB M10x80
    Länge
    80 mm
    Festigkeitsklasse
    4.6
    Gewindemaß (metrisch)
    M10
    Gewicht je Lagermengeneinheit
    0.110 kg

Stahl, galvanisch verzinkt

Article

L

Länge

Festigkeitsklasse

MG

Gewindemaß (metrisch)

G

Gewicht je Lagermengeneinheit

  • JB1030 GV
    JORDAHL Schraube JB M10x30
    Länge
    30 mm
    Festigkeitsklasse
    4.6
    Gewindemaß (metrisch)
    M10
    Gewicht je Lagermengeneinheit
    0.078 kg
  • JB1040 GV
    JORDAHL Schraube JB M10x40
    Länge
    40 mm
    Festigkeitsklasse
    4.6
    Gewindemaß (metrisch)
    M10
    Gewicht je Lagermengeneinheit
    0.083 kg
  • JB1050 GV
    JORDAHL Schraube JB M10x50
    Länge
    50 mm
    Festigkeitsklasse
    4.6
    Gewindemaß (metrisch)
    M10
    Gewicht je Lagermengeneinheit
    0.088 kg
  • JB1060 GV
    JORDAHL Schraube JB M10x60
    Länge
    60 mm
    Festigkeitsklasse
    4.6
    Gewindemaß (metrisch)
    M10
    Gewicht je Lagermengeneinheit
    0.093 kg
  • JB1080 GV
    JORDAHL Schraube JB M10x80
    Länge
    80 mm
    Festigkeitsklasse
    4.6
    Gewindemaß (metrisch)
    M10
    Gewicht je Lagermengeneinheit
    0.103 kg
  • JB10100 GV
    JORDAHL Schraube JB M10x100
    Länge
    100 mm
    Festigkeitsklasse
    4.6
    Gewindemaß (metrisch)
    M10
    Gewicht je Lagermengeneinheit
    0.113 kg

Edelstahl, Werkstoff Nr. 1.4571/1.4404 (V4A)

Article

L

Länge

MG

Gewindemaß (metrisch)

G

Gewicht je Lagermengeneinheit

  • JB1030 A4
    JORDAHL Schraube JB M10x30
    Länge
    30 mm
    Gewindemaß (metrisch)
    M10
    Gewicht je Lagermengeneinheit
    0.080 kg
  • JB1080 A4
    JORDAHL Schraube JB M10x80
    Länge
    80 mm
    Gewindemaß (metrisch)
    M10
    Gewicht je Lagermengeneinheit
    0.105 kg

Details

  • Fire protection
  • European Technical Assessment: ETA-09/0338
  • Approved throughout Europe by ETA-09/0338

Tender texts

Ausschreiben.de

Tender text for this product

Open Link
Heinze.de

Tender text for this product

Open Link

Accessories


Downloads

    Price list 2025 Shell construction / facade

    Valid from February 1, 2025

    • de

    • en

    Technical information Channels and Accessories

    Technical information

    • de

    • en

    Installation instructions T-Bolts

    • de

    • en

    ETA 09/0338 Anchor Channels JTA, JZA, JXA and JXA-PC

    • de

    • en


Included accessories
