EBW

Corner support

The corner attachment EBW is intended for maximum loads of up to 6.50 kN. It is dowelled to concrete columns and is used to attach wide-span formed parts such as bends that allow a horizontal change of direction of up to 90°. The corner fastener is suitable for formed parts and cable trays 200 to 600 mm wide and is made of hot-dip galvanised steel.

Get in touchDownload datasheet

Variants

Stahl, stück-/tauchfeuerverzinkt

Article

B

Breite

L

Länge

Pmax

max. Belastung

G

Gewicht je Lagermengeneinheit

  • EBW 020F
    Eckbefestigung für Weitspannleiterbogen
    Breite
    1400 mm
    Länge
    980 mm
    max. Belastung
    6.50 kN
    Gewicht je Lagermengeneinheit
    52.380 kg
    Included accessories
    More information
  • EBW 030F
    Eckbefestigung für Weitspannleiterbogen
    Breite
    1500 mm
    Länge
    990 mm
    max. Belastung
    6.50 kN
    Gewicht je Lagermengeneinheit
    55.050 kg
    Included accessories
    More information
  • EBW 040F
    Eckbefestigung für Weitspannleiterbogen
    Breite
    1800 mm
    Länge
    1000 mm
    max. Belastung
    6.50 kN
    Gewicht je Lagermengeneinheit
    60.370 kg
    Included accessories
    More information
  • EBW 050F
    Eckbefestigung für Weitspannleiterbogen
    Breite
    1800 mm
    Länge
    1100 mm
    max. Belastung
    6.50 kN
    Gewicht je Lagermengeneinheit
    60.380 kg
    Included accessories
    More information
  • EBW 060F
    Eckbefestigung für Weitspannleiterbogen
    Breite
    1900 mm
    Länge
    1200 mm
    max. Belastung
    6.50 kN
    Gewicht je Lagermengeneinheit
    64.370 kg
    Included accessories
    More information
