UEKD2 V E

Stainless steel hinged cover unit, 2x, angular

UEKD2 V E components are square hinged cover units with abutting edges. The levelling units consist of a cable outlet cartridge with an opening lever, floor-level cable outlet and a rubber seal. They are installed in floor sockets and raised or false floor openings and can be equipped with max. 2 mounting boxes. They are suitable for dry-cleaned and damp-cleaned rooms with office traffic loads. The cover with cable outlet and the frame are made of stainless steel V2A. The UEKD2 V E have an IP protection rating of IP 30 in an unused condition, a max. load capacity of 1.5 kN and have installation dimensions of 261 x 186 mm.

Load requirements according to: DIN EN 50085
Get in touch Download datasheet

Variants

Stainless steel, according to ASTM 304 / BS 304 S 3

Article

H

Hmin

B

L

N

Pmax

mounting box

E

IPg

IPn

T

W

  • UEKD2 15-V E
    cartridge unit,
    19 mm
    90 mm
    185 mm
    258 mm
    45 mm
    1.50 kN
    2
    261 x 186 mm
    IP 20
    IP 30
    12.5 mm
    2.330 kg
    More information
  • UEKD2 25-V E
    cartridge unit,
    29 mm
    100 mm
    185 mm
    258 mm
    45 mm
    1.50 kN
    2
    261 x 186 mm
    IP 20
    IP 30
    22.5 mm
    2.637 kg
    More information

Details

  • Load requirements according to: DIN EN 50085
