UEBD V E

Stainless steel dummy cover unit, 3x, angular

UEBD V E components are square dummy cover units with abutting edges. They consist of a cartridge mounting frame with a dummy insert cartridge and a UGD3-V 2 rubber seal. The units are mounted on UNE levelling units using UKS M4X16E Phillips screws and can be used with floor sockets, assembly covers and raised or false floor openings. They are made of stainless steel V2A or brass and are suitable for dry-cleaned and wet-cleaned rooms with office traffic loads. They have an IP protection rating of IP 54 in an unused condition and a max. load capacity of 2 kN. They are 258 mm wide, 19 mm high and have installation dimensions of 261 x 261 mm.

Load requirements according to: DIN EN 50085
Get in touch Download datasheet

Variants

brass

Article

H

height

Hmin

minimum installation height

B

width

L

length

Pmax

maximum load

E

fitting dimension

IPn

IP protection level in unused condition

T

Depth of flooring recess

G

Weight per storage unit
  • UEBD 25-V MS
    cartridge unit,
    29 mm
    95 mm
    258 mm
    258 mm
    2.00 kN
    261 x 261 mm
    IP 54
    16.5 mm
    4.971 kg
    Included accessories
    More information
  • UEBD 35-V MS
    cartridge unit,
    39 mm
    105 mm
    258 mm
    258 mm
    2.00 kN
    261 x 261 mm
    IP 54
    26.5 mm
    5.312 kg
    Included accessories
    More information

Stainless steel, according to ASTM 304 / BS 304 S 3

Article

H

height

Hmin

minimum installation height

B

width

L

length

Pmax

maximum load

E

fitting dimension

IPn

IP protection level in unused condition

T

Depth of flooring recess

G

Weight per storage unit
  • UEBD 15-V E
    cartridge unit,
    19 mm
    85 mm
    258 mm
    258 mm
    2.00 kN
    261 x 261 mm
    IP 54
    12.5 mm
    1.712 kg
    Included accessories
    More information
  • UEBD 25-V E
    cartridge unit,
    29 mm
    95 mm
    258 mm
    258 mm
    2.00 kN
    261 x 261 mm
    IP 54
    22.5 mm
    2.031 kg
    Included accessories
    More information
  • UEBD 35-V E
    cartridge unit,
    39 mm
    105 mm
    258 mm
    258 mm
    2.00 kN
    261 x 261 mm
    IP 54
    32.5 mm
    2.350 kg
    Included accessories
    More information
  • UEBD 45-V E
    cartridge unit,
    49 mm
    115 mm
    258 mm
    258 mm
    2.00 kN
    261 x 261 mm
    IP 54
    42.5 mm
    2.671 kg
    Included accessories
    More information

Details

  • Load requirements according to: DIN EN 50085
