UBDHB190 1V

False floor socket, 1x, angular

The UBDHB190 1V components are false floor sockets that are installed as pull boxes and built-in boxes on screed-covered underfloor ducts. They have a mounting hole to accommodate a formwork body, which is replaced by a square plastic installation unit during final assembly. The supplied earthing clamps are used for equipotential bonding. The floor sockets with side walls that can be bent open on all sides are made of sendzimir hot-dip galvanised sheet steel in accordance with DIN EN 10346 and have VDE/TÜV approval in accordance with DIN EN 50085.

Load requirements according to: DIN EN 50085
Get in touch Download datasheet

Variants

Article

H

Hmin

B1

B2

L1

L2

mounting box

E

Geeignet für estrichbündigen geschlossenen Unterflurkanal

Geeignet für estrichüberdeckten Unterflurkanal

W

Included accessories

  • UBDHB190 28-160V
    floor box-hollow space UBDHB190 28-160V,
    31 mm
    67 mm
    270 mm
    290 mm
    270 mm
    290 mm
    1
    165 mm
    Nein (0)
    Ja (1)
    1.391 kg
    Included accessories
    More information
  • UBDHB190 38-160V
    floor box-hollow space UBDHB190 38-160V,
    41 mm
    77 mm
    270 mm
    290 mm
    270 mm
    290 mm
    1
    165 mm
    Nein (0)
    Ja (1)
    1.455 kg
    Included accessories
    More information
  • UBDHB190 48-160V
    floor box-hollow space UBDHB190 48-160V,
    51 mm
    87 mm
    270 mm
    290 mm
    270 mm
    290 mm
    1
    165 mm
    Nein (0)
    Ja (1)
    1.515 kg
    Included accessories
    More information

Details

  • Load requirements according to: DIN EN 50085

Tender texts

Ausschreiben.de

Tender text for this product

Open Link
Heinze.de

Tender text for this product

Open Link
