RAA 110

Cable tray add-on tee, height = 110 mm

The RAA 110 cable tray attachment branch allows the direction of cable routing to be changed horizontally in the form of a branch. The side rail of the main cable tray is cut out at the point where the connection cable tray will branch off as specified in the installation instructions. The RAA attachment branch is positioned and bolted in place at this point. The VB floor connector and the connection cable tray can then be attached. The RAA 110 cable tray attachment branch is suitable for cable trays with sides 110 mm high. We provide components in various materials and surface finishes to ensure that the corrosion requirements are met for all sorts of applications.

Get in touch Download datasheet

Variants

Stahl, band-/sendzimirverzinkt

Article

H

Höhe

B

Breite

G

Gewicht je Lagermengeneinheit
  • RAA 110-10S
    Kabelrinnen-Anbauabzweig
    Höhe
    110 mm
    Breite
    100 mm
    Gewicht je Lagermengeneinheit
    1.356 kg
    Included accessories
    More information
  • RAA 110-20S
    Kabelrinnen-Anbauabzweig
    Höhe
    110 mm
    Breite
    200 mm
    Gewicht je Lagermengeneinheit
    1.484 kg
    Included accessories
    More information
  • RAA 110-30S
    Kabelrinnen-Anbauabzweig
    Höhe
    110 mm
    Breite
    300 mm
    Gewicht je Lagermengeneinheit
    1.616 kg
    Included accessories
    More information
  • RAA 110-40S
    Kabelrinnen-Anbauabzweig
    Höhe
    110 mm
    Breite
    400 mm
    Gewicht je Lagermengeneinheit
    1.752 kg
    Included accessories
    More information
  • RAA 110-50S
    Kabelrinnen-Anbauabzweig
    Höhe
    110 mm
    Breite
    500 mm
    Gewicht je Lagermengeneinheit
    1.878 kg
    Included accessories
    More information
  • RAA 110-60S
    Kabelrinnen-Anbauabzweig
    Höhe
    110 mm
    Breite
    600 mm
    Gewicht je Lagermengeneinheit
    2.014 kg
    Included accessories
    More information

Stahl, stück-/tauchfeuerverzinkt

Article

H

Höhe

B

Breite

G

Gewicht je Lagermengeneinheit
  • RAA 110-10F
    Kabelrinnen-Anbauabzweig
    Höhe
    110 mm
    Breite
    100 mm
    Gewicht je Lagermengeneinheit
    1.455 kg
    Included accessories
    More information
  • RAA 110-20F
    Kabelrinnen-Anbauabzweig
    Höhe
    110 mm
    Breite
    200 mm
    Gewicht je Lagermengeneinheit
    1.592 kg
    Included accessories
    More information
  • RAA 110-30F
    Kabelrinnen-Anbauabzweig
    Höhe
    110 mm
    Breite
    300 mm
    Gewicht je Lagermengeneinheit
    1.733 kg
    Included accessories
    More information
  • RAA 110-40F
    Kabelrinnen-Anbauabzweig
    Höhe
    110 mm
    Breite
    400 mm
    Gewicht je Lagermengeneinheit
    1.879 kg
    Included accessories
    More information
  • RAA 110-50F
    Kabelrinnen-Anbauabzweig
    Höhe
    110 mm
    Breite
    500 mm
    Gewicht je Lagermengeneinheit
    2.014 kg
    Included accessories
    More information
  • RAA 110-60F
    Kabelrinnen-Anbauabzweig
    Höhe
    110 mm
    Breite
    600 mm
    Gewicht je Lagermengeneinheit
    2.159 kg
    Included accessories
    More information

Edelstahl, Werkstoff Nr. 1.4301 (V2A)

Article

H

Höhe

B

Breite

G

Gewicht je Lagermengeneinheit
  • RAA 110-10E
    Kabelrinnen-Anbauabzweig
    Höhe
    110 mm
    Breite
    100 mm
    Gewicht je Lagermengeneinheit
    1.143 kg
    Included accessories
    More information
  • RAA 110-20E
    Kabelrinnen-Anbauabzweig
    Höhe
    110 mm
    Breite
    200 mm
    Gewicht je Lagermengeneinheit
    1.272 kg
    Included accessories
    More information
  • RAA 110-30E
    Kabelrinnen-Anbauabzweig
    Höhe
    110 mm
    Breite
    300 mm
    Gewicht je Lagermengeneinheit
    1.405 kg
    Included accessories
    More information
  • RAA 110-40E
    Kabelrinnen-Anbauabzweig
    Höhe
    110 mm
    Breite
    400 mm
    Gewicht je Lagermengeneinheit
    1.542 kg
    Included accessories
    More information
  • RAA 110-50E
    Kabelrinnen-Anbauabzweig
    Höhe
    110 mm
    Breite
    500 mm
    Gewicht je Lagermengeneinheit
    1.669 kg
    Included accessories
    More information
  • RAA 110-60E
    Kabelrinnen-Anbauabzweig
    Höhe
    110 mm
    Breite
    600 mm
    Gewicht je Lagermengeneinheit
    1.806 kg
    Included accessories
    More information

Details

  • Creates horizontal changes of the cable routing direction in the form of a branch

Tender texts

Ausschreiben.de

Tender text for this product

Open Link
Heinze.de

Tender text for this product

Open Link

Downloads

  • Price list Building extension 2025

    Valid from February 1st, 2025, updated version from 27/01/2025.
