WPRF 150

Wide-span cable tray riser, height = 150 mm

The wide-span cable tray riser WPRF 150 with integrated connectors allows the direction of cable routing to be changed vertically by 90° downwards. It is suitable for wide-span cable trays with rails 150 mm high and is 200 to 600 mm wide. The riser is pushed into the wide-span cable tray and then bolted in place. The connecting cable tray is then mounted on the riser. It has a radius of 470 mm.

Get in touch Download datasheet

Variants

Steel, hot-dip galvanised

Article

H

height

HH

Height

B

width

L

length

R

radius

direction

Direction change

W

Angle

G

Weight per storage unit
  • WPRF 150-20F
    wide-span cable tray bend WPRB 150-20F
    height
    150 mm
    Height
    150 mm
    width
    200 mm
    length
    510 mm
    radius
    470 mm
    Direction change
    vertically falling
    Angle
    90°
    Weight per storage unit
    11.520 kg
    Included accessories
    More information
  • WPRF 150-30F
    wide-span cable tray bend WPRB 150-20F
    height
    150 mm
    Height
    150 mm
    width
    300 mm
    length
    510 mm
    radius
    470 mm
    Direction change
    vertically falling
    Angle
    90°
    Weight per storage unit
    12.160 kg
    Included accessories
    More information
  • WPRF 150-40F
    wide-span cable tray bend WPRB 150-20F
    height
    150 mm
    Height
    150 mm
    width
    400 mm
    length
    510 mm
    radius
    470 mm
    Direction change
    vertically falling
    Angle
    90°
    Weight per storage unit
    12.820 kg
    Included accessories
    More information
  • WPRF 150-50F
    wide-span cable tray bend WPRB 150-20F
    height
    150 mm
    Height
    150 mm
    width
    500 mm
    length
    510 mm
    radius
    470 mm
    Direction change
    vertically falling
    Angle
    90°
    Weight per storage unit
    13.490 kg
    Included accessories
    More information
  • WPRF 150-60F
    wide-span cable tray bend WPRB 150-20F
    height
    150 mm
    Height
    150 mm
    width
    600 mm
    length
    510 mm
    radius
    470 mm
    Direction change
    vertically falling
    Angle
    90°
    Weight per storage unit
    14.150 kg
    Included accessories
    More information

Stainless steel, acc. to AISI 304 (BS 304S31)

Article

H

height

HH

Height

B

width

L

length

R

radius

direction

Direction change

W

Angle

G

Weight per storage unit
  • WPRF 150-20E
    wide-span cable tray bend WPRB 150-20F
    height
    150 mm
    Height
    150 mm
    width
    200 mm
    length
    510 mm
    radius
    470 mm
    Direction change
    vertically falling
    Angle
    90°
    Weight per storage unit
    10.838 kg
    Included accessories
    More information
  • WPRF 150-30E
    wide-span cable tray bend WPRB 150-20F
    height
    150 mm
    Height
    150 mm
    width
    300 mm
    length
    510 mm
    radius
    470 mm
    Direction change
    vertically falling
    Angle
    90°
    Weight per storage unit
    11.438 kg
    Included accessories
    More information
  • WPRF 150-40E
    wide-span cable tray bend WPRB 150-20F
    height
    150 mm
    Height
    150 mm
    width
    400 mm
    length
    510 mm
    radius
    470 mm
    Direction change
    vertically falling
    Angle
    90°
    Weight per storage unit
    12.048 kg
    Included accessories
    More information
  • WPRF 150-50E
    wide-span cable tray bend WPRB 150-20F
    height
    150 mm
    Height
    150 mm
    width
    500 mm
    length
    510 mm
    radius
    470 mm
    Direction change
    vertically falling
    Angle
    90°
    Weight per storage unit
    12.688 kg
    Included accessories
    More information
  • WPRF 150-60E
    wide-span cable tray bend WPRB 150-20F
    height
    150 mm
    Height
    150 mm
    width
    600 mm
    length
    510 mm
    radius
    470 mm
    Direction change
    vertically falling
    Angle
    90°
    Weight per storage unit
    13.308 kg
    Included accessories
    More information
