VAS-AS

Shear connector rod, stone

The approved shear connector rod VAS-AS in combination with the shear connector mortar VAB-HB M is approved or suitable for various building materials. The manufacturer's specifications must be observed. Load specifications apply depending on the substrate. The shear connector rod is available in diameters 8, 10 and 12 mm The minimum drilling depth must be 80 mm. We provide components in various materials and surface finishes to ensure that various corrosion protection requirements for different areas of application are met.

Get in touch Download datasheet

Variants

steel, galvanic zinc plated

Article

Ø

thread diameter

Lmin

min. borehole depth

G

Weight per storage unit
  • VAS-AS 8/15
    Shear connector rod, stone VAS-AS 8/15
    8 mm
    80 mm
    0.039 kg
    More information
  • VAS-AS 10/25
    Shear connector rod, stone VAS-AS 10/25
    10 mm
    80 mm
    0.066 kg
    More information
  • VAS-AS 12/40
    Shear connector rod, stone VAS-AS 12/40
    12 mm
    80 mm
    0.118 kg
    More information

Stainless steel, according to ASTM 316 Ti / AISI 316 L, BS 320S17 / BS 316S11

Article

Ø

thread diameter

Lmin

min. borehole depth

G

Weight per storage unit
