UST45 2

Socket, 2x

The UST45 2 components are one-piece, 2-way protective sockets in a 45x45 mm design. They can be inserted into the appropriate UAM cover plates using plug-in terminals. The sockets are made of high-quality polycarbonate and are available in different colours. The protective sockets have increased protection against accidental contact and are suitable for a rated voltage/current of AC 250 V, 10/16 A.

Get in touch Download datasheet

Variants

Article

H

Höhe

B

Breite

L

Länge

Farbe

Farbe

Steckwinkel

G

Gewicht je Lagermengeneinheit
  • UST45-G 2
    Schutzkontaktsteckdose,
    Höhe
    42 mm
    Breite
    40 mm
    Länge
    90 mm
    Farbe
    Grün (ähnlich RAL 6029)
    Steckwinkel
    33 °
    Gewicht je Lagermengeneinheit
    0.072 kg
    More information
  • UST45-O 2
    Schutzkontaktsteckdose,
    Höhe
    42 mm
    Breite
    40 mm
    Länge
    90 mm
    Farbe
    Orange (ähnlich RAL 2004)
    Steckwinkel
    33 °
    Gewicht je Lagermengeneinheit
    0.072 kg
    More information
  • UST45-R 2
    Schutzkontaktsteckdose,
    Höhe
    42 mm
    Breite
    40 mm
    Länge
    90 mm
    Farbe
    Rot (ähnlich RAL 3003)
    Steckwinkel
    33 °
    Gewicht je Lagermengeneinheit
    0.072 kg
    More information
  • UST45-W 2
    Schutzkontaktsteckdose,
    Höhe
    42 mm
    Breite
    40 mm
    Länge
    90 mm
    Farbe
    Weiß (ähnlich RAL 9010)
    Steckwinkel
    33 °
    Gewicht je Lagermengeneinheit
    0.072 kg
    More information
