Art.-Nr. R 35-10S

Cable tray, unperforated R 35-10S

Cable tray, unperforated, height = 35 mm

The unperforated cable trays R 35 have sides 35 mm high and are available in widths from 50 to 300 mm. The standard length is 3000 mm. We provide components in various materials and surface finishes to ensure that the corrosion requirements are met for all sorts of applications.

Art.-Nr.
R 35-10S
height
35 mm
width
100 mm
length
3000 mm
material thickness
0.75 mm
distributed load control cable
0.05 kN/m
cross section area
32 cm<sup>2</sup>
Weight per storage unit
3.731 kg
Betreten verboten
Get in touch Download datasheet

Variants

steel, continously hot galvanized/Sendzimir process

Article

H

B

L

t

QSK

A

W

  • R 35-05S
    Cable tray, unperforated
    35 mm
    50 mm
    3000 mm
    0.75 mm
    0.02 kN/m
    15 cm2
    2.850 kg
    More information
  • R 35-10S
    Cable tray, unperforated R 35-10S
    35 mm
    100 mm
    3000 mm
    0.75 mm
    0.05 kN/m
    32 cm2
    3.731 kg
    More information
  • R 35-20S
    Cable tray, unperforated R 35-20S
    35 mm
    200 mm
    3000 mm
    0.75 mm
    0.1 kN/m
    67 cm2
    5.498 kg
    More information
  • R 35-30S
    Cable tray, unperforated R 35-30S
    35 mm
    300 mm
    3000 mm
    0.75 mm
    0.15 kN/m
    102 cm2
    7.264 kg
    More information

steel, batch/hot-dip galvanized

Article

H

B

L

t

QSK

A

W

  • R 35-05F
    Cable tray
    35 mm
    50 mm
    3000 mm
    0.75 mm
    0.02 kN/m
    15 cm2
    3.200 kg
    More information
  • R 35-10F
    Cable tray, unperforated R 35-10F
    35 mm
    100 mm
    3000 mm
    0.75 mm
    0.05 kN/m
    32 cm2
    4.183 kg
    More information
  • R 35-20F
    Cable tray, unperforated R 35-20F
    35 mm
    200 mm
    3000 mm
    0.75 mm
    0.1 kN/m
    67 cm2
    6.164 kg
    More information
  • R 35-30F
    Cable tray, unperforated R 35-30F
    35 mm
    300 mm
    3000 mm
    0.75 mm
    0.15 kN/m
    102 cm2
    8.144 kg
    More information

Details

  • Betreten verboten

Tender texts

Ausschreiben.de

Tender text for this product

Open Link
Heinze.de

Tender text for this product

Open Link

Accessories

Downloads

  • Price list Building extension 2025

    Valid from February 1st, 2025, updated version from 27/01/2025.

    PDF, 46 MB

    de en

  • Cable trays - Technical information

    Technische Information

    PDF, 3 MB

    de en

  • Kabelbahnen - Katalog

    Gesamtkatalog

    PDF, 29 MB

    de
    Download

  • Cable trays - Assembly instructions

    Montageanleitung

    PDF, 3 MB

    de en

  • Kabelrinne R 60, RG 60 - Kompaktübersicht

    Kompaktübersicht

    PDF, 1 MB

    de
    Download

BIM- and CAD-Data

  • BIM for cable trays

    BIM for cable trays

    Bim data

    ZIP, 10 MB

    de en

Load diagram

Included accessories
