Art.-Nr. LGIB 60-40F

Cable ladder inside bend LGIB 60-40F

Cable ladder internal bend, height = 60 mm

The cable ladder internal bend LGIB 60 allows the direction of cable routing to be changed horizontally by 90°. They are suitable for cable ladders with rails 60 mm high and are 200 to 600 mm wide. The bend is mounted on the cable ladders using LGV side connectors (please order separately). The inner radius of the LGIB cable ladder internal bend is 400 mm and is smaller than that of the LGAB cable ladder external bend. The cable ladder can thus be guided more tightly around curves depending on the circumstances. We provide components in various materials and surface finishes to ensure that the corrosion requirements are met for all sorts of applications.

Art.-Nr.
LGIB 60-40F
height
60 mm
Height
60 mm
width
400 mm
radius
400 mm
Direction change
horizontal
Angle
90°
Weight per storage unit
3.950 kg
Get in touch Download datasheet

Variants

Steel, hot-dip galvanised

Article

H

height

HH

Height

B

width

R

radius

direction

Direction change

W

Angle

G

Weight per storage unit
  • LGIB 60-20F
    Cable ladder inside bend LGIB 60-20F
    height
    60 mm
    Height
    60 mm
    width
    200 mm
    radius
    400 mm
    Direction change
    horizontal
    Angle
    90°
    Weight per storage unit
    3.000 kg
    More information
  • LGIB 60-30F
    Cable ladder inside bend LGIB 60-30F
    height
    60 mm
    Height
    60 mm
    width
    300 mm
    radius
    400 mm
    Direction change
    horizontal
    Angle
    90°
    Weight per storage unit
    3.470 kg
    More information
  • LGIB 60-40F
    Cable ladder inside bend LGIB 60-40F
    height
    60 mm
    Height
    60 mm
    width
    400 mm
    radius
    400 mm
    Direction change
    horizontal
    Angle
    90°
    Weight per storage unit
    3.950 kg
    More information
  • LGIB 60-50F
    Cable ladder inside bend LGIB 60-50F
    height
    60 mm
    Height
    60 mm
    width
    500 mm
    radius
    400 mm
    Direction change
    horizontal
    Angle
    90°
    Weight per storage unit
    5.160 kg
    More information
  • LGIB 60-60F
    Cable ladder inside bend LGIB 60-60F
    height
    60 mm
    Height
    60 mm
    width
    600 mm
    radius
    400 mm
    Direction change
    horizontal
    Angle
    90°
    Weight per storage unit
    5.780 kg
    More information

Stainless steel, acc. to AISI 304 (BS 304S31)

Article

H

height

HH

Height

B

width

R

radius

direction

Direction change

W

Angle

G

Weight per storage unit
  • LGIB 60-20E
    Cable ladder inside bend LGIB 60-20E
    height
    60 mm
    Height
    60 mm
    width
    200 mm
    radius
    400 mm
    Direction change
    horizontal
    Angle
    90°
    Weight per storage unit
    2.820 kg
    More information
  • LGIB 60-30E
    Cable ladder inside bend LGIB 60-30E
    height
    60 mm
    Height
    60 mm
    width
    300 mm
    radius
    400 mm
    Direction change
    horizontal
    Angle
    90°
    Weight per storage unit
    3.270 kg
    More information
  • LGIB 60-40E
    Cable ladder inside bend LGIB 60-40E
    height
    60 mm
    Height
    60 mm
    width
    400 mm
    radius
    400 mm
    Direction change
    horizontal
    Angle
    90°
    Weight per storage unit
    3.720 kg
    More information
  • LGIB 60-50E
    Cable ladder inside bend LGIB 60-50E
    height
    60 mm
    Height
    60 mm
    width
    500 mm
    radius
    400 mm
    Direction change
    horizontal
    Angle
    90°
    Weight per storage unit
    4.850 kg
    More information
  • LGIB 60-60E
    Cable ladder inside bend LGIB 60-60E
    height
    60 mm
    Height
    60 mm
    width
    600 mm
    radius
    400 mm
    Direction change
    horizontal
    Angle
    90°
    Weight per storage unit
    5.440 kg
    More information

Details

  • Creates horizontal changes of the cable routing direction by 90°.
