LGVH 60

Cable ladder connector, horizontal, height = 60 mm

Horizontal changes of direction can also be implemented without formed parts. To do so, LGVH 60 horizontal connectors are pushed onto the rails of the cable ladder previously cut to size according to the installation instructions and bolted in place. The connectors can be adjusted to the required angle. The pre-cut connecting rack is then mounted using the connectors. A branch can also be set up in this way. The connector LGVH 60 is 60 mm high corresponding to the cable ladder and 150 mm long. We provide components in various materials and surface finishes to ensure that the corrosion requirements are met for all sorts of applications.

Get in touch Download datasheet

Variants

Steel, pre-galvanised/Sendzimir process

Article

H

height

L

length

G

Weight per storage unit
  • LGVH 60S
    Cable ladder coupler, horizontal
    height
    60 mm
    length
    150 mm
    Weight per storage unit
    0.216 kg
    Included accessories
    More information

Steel, hot-dip galvanised

Article

H

height

L

length

G

Weight per storage unit
  • LGVH 60F
    Cable ladder coupler, horizontal
    height
    60 mm
    length
    150 mm
    Weight per storage unit
    0.226 kg
    Included accessories
    More information

Stainless steel, acc. to AISI 304 (BS 304S31)

Article

H

height

L

length

G

Weight per storage unit
  • LGVH 60E
    Cable ladder coupler, horizontal
    height
    60 mm
    length
    150 mm
    Weight per storage unit
    0.222 kg
    Included accessories
    More information

Stainless steel, acc. to AISI 316Ti (BS 320S31) / AISI 316L (BS 316S11)

Article

H

height

L

length

G

Weight per storage unit
  • LGVH 60E4
    Cable ladder coupler, horizontal
    height
    60 mm
    length
    150 mm
    Weight per storage unit
    0.218 kg
    Included accessories
    More information

Tender texts

Ausschreiben.de

Tender text for this product

Open Link
Heinze.de

Tender text for this product

Open Link

Downloads

  • Price list Building extension 2025

    Valid from February 1st, 2025, updated version from 27/01/2025.

    PDF, 46 MB

    de en

  • Cable ladders - Assembly instructions

    Montageanleitung

    PDF, 2 MB

    de en

  • Cable ladders - Technical information

    Technical information for LGG cable ladders

    PDF, 1 MB

    de en

  • Cable Ladder LGG, LGGS

    Kompaktübersicht

    PDF, 2 MB

    de
    Download

  • Cable trays - Complete catalogue

    Catalogue for cable trays, mesh cable trays, cable ladders, wide-span systems, vertical ladders and more.

    PDF, 29 MB

    de
    Download

BIM- and CAD-Data

  • BIM for LGG cable ladders

    BIM for LGG cable ladders

    BIM data

    ZIP, 6 MB

    de en
