LGA 60

Cable ladder tee, height = 60 mm

The LGA 60 T-shaped cable ladder branch allows the direction of the cable routing to be changed in the form of a branch. It is inserted between two cable ladders and enables another cable ladder to be connected at right angles. The cable ladder branch is suitable for cable ladders with rails 60 mm high and is 200 to 600 mm wide. We provide components in various materials and surface finishes to ensure that the corrosion requirements are met for all sorts of applications.

Variants

Stahl, stück-/tauchfeuerverzinkt

Article

H

Höhe

HH

Holmhöhe

B

Breite

B2

Breite 2

R

Radius

G

Gewicht je Lagermengeneinheit

  • LGA 60-20F
    Kabelleiter-Abzweig
    Höhe
    60 mm
    Holmhöhe
    60 mm
    Breite
    200 mm
    Breite 2
    200 mm
    Radius
    400 mm
    Gewicht je Lagermengeneinheit
    4.690 kg
  • LGA 60-30F
    Kabelleiter-Abzweig
    Höhe
    60 mm
    Holmhöhe
    60 mm
    Breite
    300 mm
    Breite 2
    300 mm
    Radius
    400 mm
    Gewicht je Lagermengeneinheit
    5.390 kg
  • LGA 60-40F
    Kabelleiter-Abzweig
    Höhe
    60 mm
    Holmhöhe
    60 mm
    Breite
    400 mm
    Breite 2
    400 mm
    Radius
    400 mm
    Gewicht je Lagermengeneinheit
    6.100 kg
  • LGA 60-50F
    Kabelleiter-Abzweig
    Höhe
    60 mm
    Holmhöhe
    60 mm
    Breite
    500 mm
    Breite 2
    500 mm
    Radius
    400 mm
    Gewicht je Lagermengeneinheit
    6.800 kg
  • LGA 60-60F
    Kabelleiter-Abzweig
    Höhe
    60 mm
    Holmhöhe
    60 mm
    Breite
    600 mm
    Breite 2
    600 mm
    Radius
    400 mm
    Gewicht je Lagermengeneinheit
    7.510 kg

Edelstahl, Werkstoff Nr. 1.4301 (V2A)

Article

H

Höhe

HH

Holmhöhe

B

Breite

B2

Breite 2

R

Radius

G

Gewicht je Lagermengeneinheit

  • LGA 60-20E
    Kabelleiter-Abzweig
    Höhe
    60 mm
    Holmhöhe
    60 mm
    Breite
    200 mm
    Breite 2
    200 mm
    Radius
    400 mm
    Gewicht je Lagermengeneinheit
    4.410 kg
  • LGA 60-30E
    Kabelleiter-Abzweig
    Höhe
    60 mm
    Holmhöhe
    60 mm
    Breite
    300 mm
    Breite 2
    300 mm
    Radius
    400 mm
    Gewicht je Lagermengeneinheit
    5.070 kg
  • LGA 60-40E
    Kabelleiter-Abzweig
    Höhe
    60 mm
    Holmhöhe
    60 mm
    Breite
    400 mm
    Breite 2
    400 mm
    Radius
    400 mm
    Gewicht je Lagermengeneinheit
    5.740 kg
  • LGA 60-50E
    Kabelleiter-Abzweig
    Höhe
    60 mm
    Holmhöhe
    60 mm
    Breite
    500 mm
    Breite 2
    500 mm
    Radius
    400 mm
    Gewicht je Lagermengeneinheit
    6.400 kg
  • LGA 60-60E
    Kabelleiter-Abzweig
    Höhe
    60 mm
    Holmhöhe
    60 mm
    Breite
    600 mm
    Breite 2
    600 mm
    Radius
    400 mm
    Gewicht je Lagermengeneinheit
    7.060 kg

Details

  • Creates horizontal changes of the cable routing direction in the form of a branch
