BKAA 100

Floor duct add-on tee, height = 100 mm

The BKAA 100 floor duct attachment branch with integrated connectors allows the direction of cable routing to be changed horizontally by 90°. It is 100 mm high and 100 to 600 mm wide. It is made of sendzimir hot-dip galvanised steel. To dissipate vertical live loads, one separating strip must be installed in the floor duct for widths ≥ 300 mm and two separating strips for widths ≥ 500 mm. The side rail of the main floor duct is cut out accordingly at the point where the connecting floor duct will branch off. The BKAA attachment branch is positioned and bolted in place at this point. The branching floor duct can then be pushed in.

Get in touch Download datasheet

Variants

Steel, pre-galvanised/Sendzimir process

Article

H

height

B

width

t

material thickness

W

Angle

G

Weight per storage unit
  • BKAA 100-10S
    Floor duct attachment branch, 90° T-branch,
    height
    100 mm
    width
    100 mm
    material thickness
    2.00 mm
    Angle
    90°
    Weight per storage unit
    1.316 kg
    Included accessories
    More information
  • BKAA 100-15S
    Floor duct attachment branch, 90° T-branch,
    height
    100 mm
    width
    150 mm
    material thickness
    2.00 mm
    Angle
    90°
    Weight per storage unit
    1.456 kg
    Included accessories
    More information
  • BKAA 100-20S
    Floor duct attachment branch, 90° T-branch,
    height
    100 mm
    width
    200 mm
    material thickness
    2.00 mm
    Angle
    90°
    Weight per storage unit
    1.536 kg
    Included accessories
    More information
  • BKAA 100-30S
    Floor duct attachment branch, 90° T-branch,
    height
    100 mm
    width
    300 mm
    material thickness
    2.00 mm
    Angle
    90°
    Weight per storage unit
    1.756 kg
    Included accessories
    More information
  • BKAA 100-40S
    Floor duct attachment branch, 90° T-branch,
    height
    100 mm
    width
    400 mm
    material thickness
    2.00 mm
    Angle
    90°
    Weight per storage unit
    1.966 kg
    Included accessories
    More information
  • BKAA 100-50S
    Floor duct attachment branch, 90° T-branch,
    height
    100 mm
    width
    500 mm
    material thickness
    2.00 mm
    Angle
    90°
    Weight per storage unit
    2.186 kg
    Included accessories
    More information
  • BKAA 100-60S
    Floor duct attachment branch, 90° T-branch,
    height
    100 mm
    width
    600 mm
    material thickness
    2.00 mm
    Angle
    90°
    Weight per storage unit
    2.406 kg
    Included accessories
    More information

Details

  • Changes the cable routing direction horizontally in the form of a branch of 90°.
  • Cable-friendly guide

Tender texts

Ausschreiben.de

Tender text for this product

Open Link
Heinze.de

Tender text for this product

Open Link

Downloads

  • Price list Building extension 2025

    Valid from February 1st, 2025, updated version from 27/01/2025.

    PDF, 46 MB
