BGUQ 50

Bolted head plate turned 90°, STU 50

The head plate BGUQ 50 with a plate turned at right angles to the rail is used to attach the STU 50 vertical ladders to the ceiling and/or floor. We provide components in various materials and surface finishes to ensure that the corrosion requirements are met for all sorts of applications.

Get in touch Download datasheet

Variants

Stahl, stück-/tauchfeuerverzinkt

Article

H

Höhe

B

Breite

L

Länge

G

Gewicht je Lagermengeneinheit
  • BGUQ 50F
    Kopfplatte
    Höhe
    156 mm
    Breite
    80 mm
    Länge
    150 mm
    Gewicht je Lagermengeneinheit
    0.993 kg
    Included accessories
    More information

Edelstahl, Werkstoff Nr. 1.4301 (V2A)

Article

H

Höhe

B

Breite

L

Länge

G

Gewicht je Lagermengeneinheit
  • BGUQ 50E
    Kopfplatte
    Höhe
    156 mm
    Breite
    80 mm
    Länge
    150 mm
    Gewicht je Lagermengeneinheit
    0.939 kg
    Included accessories
    More information
