Variants
Stahl, stück-/tauchfeuerverzinkt
H
Höhe
B
Breite
L
Länge
t
Materialstärke
G
Gewicht je Lagermengeneinheit
- AVT F
ProfilschienenverbinderHöhe99 mmBreite46 mmLänge145 mmMaterialstärke5 mmGewicht je Lagermengeneinheit0.615 kg
Channel joint connector
The channel joint connector AVT is used to connect three mounting channels (A 41, KHA 41, KHAL 41), one continuous channel and two in a T-joint. The two joints are aligned, orientated to the right and left of the continuous rail. It has Ø 13 mm fixing holes and is made of hot-dip galvanised steel. Fastening accessories must be ordered separately, depending on the application.
H
Höhe
B
Breite
L
Länge
t
Materialstärke
G
Gewicht je Lagermengeneinheit
Valid from February 1st, 2025, updated version from 27/01/2025.
