WPTRV 100

Wide-span cable tray divider, flexible, height = 50 mm

Cables and wires with different functions or voltages can be routed separately from one another by using the variable wide-span separating strip WPTRV 100. The separating strip is separated into segments. This makes it flexible and ideal for being installed in formed parts. Mounting bolts are included. The wide-span separating strip is 50 mm high and 1000 mm long. We provide components in various materials and surface finishes to ensure that various corrosion protection requirements for different areas of application are met.

Get in touchDownload datasheet

Variants

Stainless steel, acc. to AISI 304 (BS 304S31)

Article

H

height

L

length

t

material thickness

G

Weight per storage unit

  • WPTRV 100E
    Wide-span barrier strip
    height
    50 mm
    length
    1000 mm
    material thickness
    0.80 mm
    Weight per storage unit
    0.540 kg
    Included accessories
    More information

Stainless steel, acc. to AISI 316Ti (BS 320S31) / AISI 316L (BS 316S11)

Article

H

height

L

length

t

material thickness

G

Weight per storage unit

  • WPTRV 100E4
    Wide-span barrier strip
    height
    50 mm
    length
    1000 mm
    material thickness
    0.80 mm
    Weight per storage unit
    0.551 kg
    Included accessories
    More information
