Art.-Nr. WPRF 120-60F

Wide-span cable tray drop section

Wide-span cable tray riser, height = 120 mm

The wide-span cable tray riser WPRF 120 with integrated connectors allows the direction of cable routing to be changed vertically by 90° downwards. It is suitable for wide-span cable trays with rails 120 mm high and is 200 to 600 mm wide. The riser is pushed into the wide-span cable tray and then bolted in place. The connecting cable tray is then mounted on the riser. It has a radius of 500 mm.

Art.-Nr.
WPRF 120-60F
height
120 mm
width
600 mm
length
540 mm
radius
500 mm
Direction change
vertically falling
Angle
90°
Weight per storage unit
12.480 kg
Get in touchDownload datasheet

Variants

Steel, hot-dip galvanised

Article

H

height

B

width

L

length

R

radius

direction

Direction change

W

Angle

G

Weight per storage unit

  • WPRF 120-20F
    Wide-span cable tray drop section
    height
    120 mm
    width
    200 mm
    length
    540 mm
    radius
    500 mm
    Direction change
    vertically falling
    Angle
    90°
    Weight per storage unit
    9.690 kg
    Included accessories
    More information
  • WPRF 120-30F
    Wide-span cable tray drop section
    height
    120 mm
    width
    300 mm
    length
    540 mm
    radius
    500 mm
    Direction change
    vertically falling
    Angle
    90°
    Weight per storage unit
    10.370 kg
    Included accessories
    More information
  • WPRF 120-40F
    Wide-span cable tray drop section
    height
    120 mm
    width
    400 mm
    length
    540 mm
    radius
    500 mm
    Direction change
    vertically falling
    Angle
    90°
    Weight per storage unit
    11.080 kg
    Included accessories
    More information
  • WPRF 120-50F
    Wide-span cable tray drop section
    height
    120 mm
    width
    500 mm
    length
    540 mm
    radius
    500 mm
    Direction change
    vertically falling
    Angle
    90°
    Weight per storage unit
    11.780 kg
    Included accessories
    More information
  • WPRF 120-60F
    Wide-span cable tray drop section
    height
    120 mm
    width
    600 mm
    length
    540 mm
    radius
    500 mm
    Direction change
    vertically falling
    Angle
    90°
    Weight per storage unit
    12.480 kg
    Included accessories
    More information
