WPREB

Wide-span cable tray end plate

The wide-span cable tray end plate WPREB is pushed onto the tray bottom at the end of a wide-span cable tray and bolted in place. It is used to protect the cables that are fed in or out. It is also suitable for use as an intermediate element when connecting two wide-span cable trays horizontally or vertically using side connectors. The wide-span cable tray end plate is from 195 to 595 mm wide corresponding to the cable tray. We provide components in various materials and surface finishes to ensure that various corrosion protection requirements for different areas of application are met.

Get in touch Download datasheet

Variants

steel, continously hot galvanized/Sendzimir process

Article

H

B

L

W

Included accessories

  • WPREB 20S
    End plate, Wide-span cable tray WPREB
    6 mm
    90 mm
    195 mm
    0.126 kg
    Included accessories
    More information
  • WPREB 30S
    End plate, Wide-span cable tray WPREB
    6 mm
    90 mm
    295 mm
    0.185 kg
    Included accessories
    More information
  • WPREB 40S
    End plate, Wide-span cable tray WPREB
    6 mm
    90 mm
    395 mm
    0.244 kg
    Included accessories
    More information
  • WPREB 50S
    End plate, Wide-span cable tray WPREB
    6 mm
    90 mm
    495 mm
    0.302 kg
    Included accessories
    More information
  • WPREB 60S
    End plate, Wide-span cable tray WPREB
    6 mm
    90 mm
    595 mm
    0.361 kg
    Included accessories
    More information

steel, batch/hot-dip galvanized

Article

H

B

L

W

Included accessories

  • WPREB 20F
    End plate, Wide-span cable tray WPREB
    6 mm
    90 mm
    195 mm
    0.136 kg
    Included accessories
    More information
  • WPREB 30F
    End plate, Wide-span cable tray WPREB
    6 mm
    90 mm
    295 mm
    0.196 kg
    Included accessories
    More information
  • WPREB 40F
    End plate, Wide-span cable tray WPREB
    6 mm
    90 mm
    395 mm
    0.266 kg
    Included accessories
    More information
  • WPREB 50F
    End plate, Wide-span cable tray WPREB
    6 mm
    90 mm
    495 mm
    0.326 kg
    Included accessories
    More information
  • WPREB 60F
    End plate, Wide-span cable tray WPREB
    6 mm
    90 mm
    595 mm
    0.386 kg
    Included accessories
    More information

Tender texts

Ausschreiben.de

Tender text for this product

Open Link
Heinze.de

Tender text for this product

Open Link

Downloads

  • Price list Building extension 2025

    Valid from February 1st, 2025, updated version from 27/01/2025.

    PDF, 46 MB

    de en

  • Weitspannkabelleitern WPL, Montageanleitung

    Montageanleitung

    PDF, 2 MB

    de
    Download

  • Weitspannkabelrinnen WPR, Montageanleitung

    Montageanleitung

    PDF, 2 MB

    de
    Download

  • Wide-Span Systems, Technical Information

    Technische Information

    PDF, 4 MB

    de en

BIM- and CAD-Data

  • BIM Daten Weitspannbahnen (Revit)

    BIM Daten Weitspannbahnen (Revit)

    BIM-Daten

    ZIP, 12 MB

    de
    Download

Included accessories
