UGE3 RE

Mounting box insert, 3x, for stainless steel units, round

The UGE3 RE components are service outlets with side panels that can be bolted into round stainless steel installation units suitable for a maximum of three mounting boxes. The inserts can be equipped with up to four installation devices measuring 45x45 mm and up to 6 single data jacks. They are made of sendzimir hot-dip galvanised sheet steel in accordance with DIN EN 10346.

Load requirements according to: DIN EN 50085
Get in touch Download datasheet

Variants

Article

H

Höhe

Hmin

min. Einbauhöhe

B

Breite

L

Länge

Datenjacks

max. Anzahl installierbarer Datenjacks

E1

Einbaumaß E1

E2

Einbaumaß E2

G

Gewicht je Lagermengeneinheit

Installationsgeräte

max. Anzahl Installationsgeräte
  • UGE3-RE 4
    Geräteeinsatz,
    Höhe
    47 mm
    min. Einbauhöhe
    100 mm
    Breite
    235 mm
    Länge
    231 mm
    max. Anzahl installierbarer Datenjacks
    6
    Einbaumaß E1
    90 mm
    Einbaumaß E2
    46 mm
    Gewicht je Lagermengeneinheit
    0.565 kg
    max. Anzahl Installationsgeräte
    4x 45x45 mm
    More information

Details

  • Load requirements according to: DIN EN 50085
