UEKD2 R E

Stainless steel hinged cover unit, 2x, round

UEKD2 R E components are round hinged cover units with abutting edges. They can accommodate a maximum of two mounting boxes. They consist of a height-adjustable cartridge mounting frame with a cable outlet cartridge, an opening lever and a rubber seal. The units are suitable for installation in UBDHB floor sockets, assembly covers and raised or false floor openings in wet-cleaned and damp-cleaned rooms with office traffic loads. Both the cartridge and frame are made of stainless steel V2A. They have an IP protection class of IP 30 in an unused condition, a maximum load capacity of 2 kN, an adjustment range of 55 mm, an installation dimension of 260 mm and a minimum installation height of 100 mm.

Load requirements according to: DIN EN 50085
Get in touch Download datasheet

Variants

Edelstahl, Werkstoff Nr. 1.4301 (V2A)

Article

H

Höhe

Hmin

min. Einbauhöhe

N

Nivellierbereich

Pmax

max. Belastung

ØB

Einbaudurchmesser

Gerätebecher

max. Anzahl installierbarer Gerätebecher

ØE

Einbaumaß

IPg

IP-Schutzgrad im genutzten Zustand

IPn

IP-Schutzgrad im nicht genutzten Zustand

T

Tiefe der Bodenbelagaussparung

G

Gewicht je Lagermengeneinheit
  • UEKD2 15-R E
    Kassetteneinheit,
    Höhe
    18 mm
    min. Einbauhöhe
    100 mm
    Nivellierbereich
    55 mm
    max. Belastung
    2.00 kN
    Einbaudurchmesser
    258 mm
    max. Anzahl installierbarer Gerätebecher
    2
    Einbaumaß
    260 mm
    IP-Schutzgrad im genutzten Zustand
    IP 20
    IP-Schutzgrad im nicht genutzten Zustand
    IP 30
    Tiefe der Bodenbelagaussparung
    12 mm
    Gewicht je Lagermengeneinheit
    2.165 kg
    Included accessories
    More information
  • UEKD2 25-R E
    Kassetteneinheit,
    Höhe
    28 mm
    min. Einbauhöhe
    110 mm
    Nivellierbereich
    55 mm
    max. Belastung
    2.00 kN
    Einbaudurchmesser
    258 mm
    max. Anzahl installierbarer Gerätebecher
    2
    Einbaumaß
    260 mm
    IP-Schutzgrad im genutzten Zustand
    IP 20
    IP-Schutzgrad im nicht genutzten Zustand
    IP 30
    Tiefe der Bodenbelagaussparung
    22 mm
    Gewicht je Lagermengeneinheit
    2.425 kg
    Included accessories
    More information

Details

  • Load requirements according to: DIN EN 50085
