UEBSD

Dummy cover

UEBSD components are dummy covers for use with screed-flush duct systems. The products are made of sendzimir hot-dip galvanised sheet steel in accordance with DIN EN 10346. They are firmly bolted to the UEBSQT transverse cross-beams at the factory and are supplied in versions 200 to 500 mm wide, 500 mm long and with material 3 mm thick. The dummy covers have received VDE/TÜV approval in accordance with DIN EN 50085.

Load requirements according to: DIN EN 50085
Get in touch Download datasheet

Variants

Article

B

width

L

length

t

material thickness

G

Weight per storage unit
  • UEBSD 20S
    dummy cover,
    200 mm
    500 mm
    3.00 mm
    2.473 kg
    Included accessories
    More information
  • UEBSD 30S
    dummy cover,
    300 mm
    500 mm
    3.00 mm
    3.763 kg
    Included accessories
    More information
  • UEBSD 40S
    dummy cover,
    400 mm
    500 mm
    3.00 mm
    5.540 kg
    Included accessories
    More information
  • UEBSD 50S
    dummy cover,
    500 mm
    500 mm
    3.00 mm
    8.111 kg
    Included accessories
    More information

Details

  • Load requirements according to: DIN EN 50085
