UBKDB

Spacer

UBKDB components are spacer plates that are an element of screed-flush heavy-duty ducts. During installation, the sheets are inserted into the pre-assembled side profiles of the duct undersides before the screed is applied. They are removed again after the screed has hardened. They are made of sendzimir hot-dip galvanised sheet steel in accordance with DIN EN 10346. They are 60 mm long, made from material 4 mm thick and come in various widths.

Get in touch Download datasheet

Variants

UBKDB5 25
Distanzblech,
Höhe
4 mm
Breite
242 mm
Länge
60 mm
Materialstärke
4.00 mm
Gewicht je Lagermengeneinheit
0.456 kg
More information
UBKDB5 35
Distanzblech,
Höhe
4 mm
Breite
342 mm
Länge
60 mm
Materialstärke
4.00 mm
Gewicht je Lagermengeneinheit
0.644 kg
More information
UBKDB5 45
Distanzblech,
Höhe
4 mm
Breite
442 mm
Länge
60 mm
Materialstärke
4.00 mm
Gewicht je Lagermengeneinheit
0.833 kg
More information
UBKDB8 25
Distanzblech,
Höhe
4 mm
Breite
254 mm
Länge
60 mm
Materialstärke
4.00 mm
Gewicht je Lagermengeneinheit
0.479 kg
More information
UBKDB8 35
Distanzblech,
Höhe
4 mm
Breite
354 mm
Länge
60 mm
Materialstärke
4.00 mm
Gewicht je Lagermengeneinheit
0.667 kg
More information
UBKDB8 45
Distanzblech,
Höhe
4 mm
Breite
454 mm
Länge
60 mm
Materialstärke
4.00 mm
Gewicht je Lagermengeneinheit
0.855 kg
More information
