STUS 60

STUS 60

Rung

The rungs STUS 60 can be installed in the course of or also after vertical ladder installation and are bolted to the side rail. They are suitable for STU 60 vertical ladders and are 200 to 1200 mm wide corresponding to the vertical ladder width. We provide components in various materials and surface finishes to ensure that the corrosion requirements are met for all sorts of applications.

Get in touch Download datasheet

Variants

Steel, hot-dip galvanised

STUS 60-02F
Vertical ladder STU 60-02F
height
22 mm
width
200 mm
length
40 mm
Weight per storage unit
0.384 kg
Included accessories
More information
STUS 60-03F
Vertical ladder STU 60-03F
height
22 mm
width
300 mm
length
40 mm
Weight per storage unit
0.534 kg
Included accessories
More information
STUS 60-04F
Vertical ladder STU 60-04F
height
22 mm
width
400 mm
length
40 mm
Weight per storage unit
0.694 kg
Included accessories
More information
STUS 60-05F
Vertical ladder STU 60-05F
height
22 mm
width
500 mm
length
40 mm
Weight per storage unit
0.844 kg
Included accessories
More information
STUS 60-06F
Vertical ladder STU 60-06F
height
22 mm
width
600 mm
length
40 mm
Weight per storage unit
1.004 kg
Included accessories
More information
STUS 60-07F
Vertical ladder STU 60-07F
height
22 mm
width
700 mm
length
40 mm
Weight per storage unit
1.154 kg
Included accessories
More information
STUS 60-08F
Vertical ladder STU 60-08F
height
22 mm
width
800 mm
length
40 mm
Weight per storage unit
1.314 kg
Included accessories
More information
STUS 60-09F
Vertical ladder STU 60-09F
height
22 mm
width
900 mm
length
40 mm
Weight per storage unit
1.464 kg
Included accessories
More information
STUS 60-10F
Vertical ladder STU 60-10F
height
22 mm
width
1000 mm
length
40 mm
Weight per storage unit
1.614 kg
Included accessories
More information
STUS 60-11F
Vertical ladder STU 60-11F
height
22 mm
width
1100 mm
length
40 mm
Weight per storage unit
1.774 kg
Included accessories
More information
STUS 60-12F
Vertical ladder STU 60-12F
height
22 mm
width
1200 mm
length
40 mm
Weight per storage unit
1.924 kg
Included accessories
More information

Stainless steel, acc. to AISI 304 (BS 304S31)

STUS 60-02E
Vertical ladder STU 60-02F
height
22 mm
width
200 mm
length
40 mm
Weight per storage unit
0.364 kg
Included accessories
More information
STUS 60-03E
Vertical ladder STU 60-02F
height
22 mm
width
300 mm
length
40 mm
Weight per storage unit
0.514 kg
Included accessories
More information
STUS 60-04E
Vertical ladder STU 60-02F
height
22 mm
width
400 mm
length
40 mm
Weight per storage unit
0.664 kg
Included accessories
More information
STUS 60-05E
Vertical ladder STU 60-02F
height
22 mm
width
500 mm
length
40 mm
Weight per storage unit
0.814 kg
Included accessories
More information
STUS 60-06E
Vertical ladder STU 60-02F
height
22 mm
width
600 mm
length
40 mm
Weight per storage unit
0.954 kg
Included accessories
More information
STUS 60-07E
Vertical ladder STU 60-02F
height
22 mm
width
700 mm
length
40 mm
Weight per storage unit
1.104 kg
Included accessories
More information
STUS 60-08E
Vertical ladder STU 60-02F
height
22 mm
width
800 mm
length
40 mm
Weight per storage unit
1.254 kg
Included accessories
More information
STUS 60-09E
Vertical ladder STU 60-02F
height
22 mm
width
900 mm
length
40 mm
Weight per storage unit
1.394 kg
Included accessories
More information
STUS 60-10E
Vertical ladder STU 60-02F
height
22 mm
width
1000 mm
length
40 mm
Weight per storage unit
1.544 kg
Included accessories
More information
STUS 60-11E
Vertical ladder STU 60-02F
height
22 mm
width
1100 mm
length
40 mm
Weight per storage unit
1.694 kg
Included accessories
More information
STUS 60-12E
Vertical ladder STU 60-02F
height
22 mm
width
1200 mm
length
40 mm
Weight per storage unit
1.834 kg
Included accessories
More information

Tender texts

Ausschreiben.de

Tender texts for this product

Open Link

Heinze.de

Tender texts for this product

Open Link

Downloads

**Price list 2025 Building extension**
Valid from February 1st, 2025, updated version from 31/03/2025.
