STISD

Rung

The rungs STISD are installed while fitting the vertical ladder and bolted to the side rail. They are suitable for ST 82 vertical ladders for double-sided cable assignment. They are 200 to 1200 mm wide corresponding to the vertical ladder width and are made of hot-dip galvanised steel.

Get in touchDownload datasheet

Variants

Stahl, stück-/tauchfeuerverzinkt

Article

H

Höhe

B

Breite

L

Länge

G

Gewicht je Lagermengeneinheit

  • STISD 02F
    Sprosse 82
    Höhe
    44 mm
    Breite
    200 mm
    Länge
    40 mm
    Gewicht je Lagermengeneinheit
    1.149 kg
    Included accessories
    More information
  • STISD 03F
    Sprosse 82
    Höhe
    44 mm
    Breite
    300 mm
    Länge
    40 mm
    Gewicht je Lagermengeneinheit
    1.464 kg
    Included accessories
    More information
  • STISD 04F
    Sprosse 82
    Höhe
    44 mm
    Breite
    400 mm
    Länge
    40 mm
    Gewicht je Lagermengeneinheit
    1.782 kg
    Included accessories
    More information
  • STISD 05F
    Sprosse 82
    Höhe
    44 mm
    Breite
    500 mm
    Länge
    40 mm
    Gewicht je Lagermengeneinheit
    2.094 kg
    Included accessories
    More information
  • STISD 06F
    Sprosse 82
    Höhe
    44 mm
    Breite
    600 mm
    Länge
    40 mm
    Gewicht je Lagermengeneinheit
    2.269 kg
    Included accessories
    More information
  • STISD 07F
    Sprosse 82
    Höhe
    44 mm
    Breite
    700 mm
    Länge
    40 mm
    Gewicht je Lagermengeneinheit
    2.733 kg
    Included accessories
    More information
  • STISD 08F
    Sprosse 82
    Höhe
    44 mm
    Breite
    800 mm
    Länge
    40 mm
    Gewicht je Lagermengeneinheit
    3.058 kg
    Included accessories
    More information
  • STISD 09F
    Sprosse 82
    Höhe
    44 mm
    Breite
    900 mm
    Länge
    40 mm
    Gewicht je Lagermengeneinheit
    3.373 kg
    Included accessories
    More information
  • STISD 10F
    Sprosse 82
    Höhe
    44 mm
    Breite
    1000 mm
    Länge
    40 mm
    Gewicht je Lagermengeneinheit
    3.698 kg
    Included accessories
    More information
  • STISD 11F
    Sprosse 82
    Höhe
    44 mm
    Breite
    1100 mm
    Länge
    40 mm
    Gewicht je Lagermengeneinheit
    4.013 kg
    Included accessories
    More information
  • STISD 12F
    Sprosse 82
    Höhe
    44 mm
    Breite
    1200 mm
    Länge
    40 mm
    Gewicht je Lagermengeneinheit
    4.332 kg
    Included accessories
    More information
