STDE

Vertical ladder collision protection

Collision protection STDE with integrated handle openings for attachment to vertical ladders are suitable for ST 81/82 vertical ladders. The collision protection is 120 or 150 mm high, 200 to 1200 mm wide and 2000 mm long. We provide components in various materials and surface finishes to ensure that the corrosion requirements are met for all sorts of applications.

Get in touch Download datasheet

Variants

steel, continously hot galvanized/Sendzimir process

Article

H

B

L

t

W

Included accessories

  • STDE 120-20S
    Vertical ladder ST 81-02F
    120 mm
    200 mm
    2000 mm
    2.00 mm
    21.390 kg
    Included accessories
    More information
  • STDE 120-30S
    Vertical ladder ST 81-02F
    120 mm
    300 mm
    2000 mm
    2.00 mm
    21.390 kg
    Included accessories
    More information
  • STDE 120-40S
    Vertical ladder ST 81-02F
    120 mm
    400 mm
    2000 mm
    2.00 mm
    24.530 kg
    Included accessories
    More information
  • STDE 120-50S
    Vertical ladder ST 81-02F
    120 mm
    500 mm
    2000 mm
    2.00 mm
    27.670 kg
    Included accessories
    More information
  • STDE 120-60S
    Vertical ladder ST 81-02F
    120 mm
    600 mm
    2000 mm
    2.00 mm
    30.810 kg
    Included accessories
    More information
  • STDE 120-70S
    Vertical ladder ST 81-02F
    120 mm
    700 mm
    2000 mm
    2.00 mm
    33.950 kg
    Included accessories
    More information
  • STDE 120-80S
    Vertical ladder ST 81-02F
    120 mm
    800 mm
    2000 mm
    2.00 mm
    37.090 kg
    Included accessories
    More information
  • STDE 120-90S
    Vertical ladder ST 81-02F
    120 mm
    900 mm
    2000 mm
    2.00 mm
    40.230 kg
    Included accessories
    More information
  • STDE 120-100S
    Vertical ladder ST 81-02F
    120 mm
    1000 mm
    2000 mm
    2.00 mm
    43.370 kg
    Included accessories
    More information
  • STDE 120-110S
    Vertical ladder ST 81-02F
    120 mm
    1100 mm
    2000 mm
    2.00 mm
    49.990 kg
    Included accessories
    More information
  • STDE 120-120S
    Vertical ladder ST 81-02F
    120 mm
    1200 mm
    2000 mm
    2.00 mm
    53.130 kg
    Included accessories
    More information
  • STDE 150-20S
    Vertical ladder ST 81-02F
    150 mm
    200 mm
    2000 mm
    2.00 mm
    20.140 kg
    Included accessories
    More information
  • STDE 150-30S
    Vertical ladder ST 81-02F
    150 mm
    300 mm
    2000 mm
    2.00 mm
    23.280 kg
    Included accessories
    More information
  • STDE 150-40S
    Vertical ladder ST 81-02F
    150 mm
    400 mm
    2000 mm
    2.00 mm
    26.420 kg
    Included accessories
    More information
  • STDE 150-50S
    Vertical ladder ST 81-02F
    150 mm
    500 mm
    2000 mm
    2.00 mm
    29.560 kg
    Included accessories
    More information
  • STDE 150-60S
    Vertical ladder ST 81-02F
    150 mm
    600 mm
    2000 mm
    2.00 mm
    32.700 kg
    Included accessories
    More information
  • STDE 150-70S
    Vertical ladder ST 81-02F
    150 mm
    700 mm
    2000 mm
    2.00 mm
    35.840 kg
    Included accessories
    More information
  • STDE 150-80S
    Vertical ladder ST 81-02F
    150 mm
    800 mm
    2000 mm
    2.00 mm
    38.980 kg
    Included accessories
    More information
  • STDE 150-90S
    Vertical ladder ST 81-02F
    150 mm
    900 mm
    2000 mm
    2.00 mm
    42.120 kg
    Included accessories
    More information
  • STDE 150-100S
    Vertical ladder ST 81-02F
    150 mm
    1000 mm
    2000 mm
    2.00 mm
    45.260 kg
    Included accessories
    More information
  • STDE 150-110S
    Vertical ladder ST 81-02F
    150 mm
    1100 mm
    2000 mm
    2.00 mm
    51.870 kg
    Included accessories
    More information
  • STDE 150-120S
    Vertical ladder ST 81-02F
    150 mm
    1200 mm
    2000 mm
    2.00 mm
    55.010 kg
    Included accessories
    More information

steel, batch/hot-dip galvanized

Article

H

B

L

t

W

Included accessories

  • STDE 120-20F
    Vertical ladder ST 81-02F
    120 mm
    200 mm
    2000 mm
    2.00 mm
    19.432 kg
    Included accessories
    More information
  • STDE 120-30F
    Vertical ladder ST 81-02F
    120 mm
    300 mm
    2000 mm
    2.00 mm
    22.792 kg
    Included accessories
    More information
  • STDE 120-40F
    Vertical ladder ST 81-02F
    120 mm
    400 mm
    2000 mm
    2.00 mm
    26.152 kg
    Included accessories
    More information
  • STDE 120-50F
    Vertical ladder ST 81-02F
    120 mm
    500 mm
    2000 mm
    2.00 mm
    29.512 kg
    Included accessories
    More information
  • STDE 120-60F
    Vertical ladder ST 81-02F
    120 mm
    600 mm
    2000 mm
    2.00 mm
    32.872 kg
    Included accessories
    More information
  • STDE 120-70F
    Vertical ladder ST 81-02F
    120 mm
    700 mm
    2000 mm
    2.00 mm
    36.232 kg
    Included accessories
    More information
  • STDE 120-80F
    Vertical ladder ST 81-02F
    120 mm
    800 mm
    2000 mm
    2.00 mm
    39.592 kg
    Included accessories
    More information
  • STDE 120-90F
    Vertical ladder ST 81-02F
    120 mm
    900 mm
    2000 mm
    2.00 mm
    42.952 kg
    Included accessories
    More information
  • STDE 120-100F
    Vertical ladder ST 81-02F
    120 mm
    1000 mm
    2000 mm
    2.00 mm
    46.312 kg
    Included accessories
    More information
  • STDE 120-110F
    Vertical ladder ST 81-02F
    120 mm
    1100 mm
    2000 mm
    2.00 mm
    53.372 kg
    Included accessories
    More information
  • STDE 120-120F
    Vertical ladder ST 81-02F
    120 mm
    1200 mm
    2000 mm
    2.00 mm
    56.732 kg
    Included accessories
    More information
  • STDE 150-20F
    Vertical ladder ST 81-02F
    150 mm
    200 mm
    2000 mm
    2.00 mm
    21.452 kg
    Included accessories
    More information
  • STDE 150-30F
    Vertical ladder ST 81-02F
    150 mm
    300 mm
    2000 mm
    2.00 mm
    24.542 kg
    Included accessories
    More information
  • STDE 150-40F
    Vertical ladder ST 81-02F
    150 mm
    400 mm
    2000 mm
    2.00 mm
    28.172 kg
    Included accessories
    More information
  • STDE 150-50F
    Vertical ladder ST 81-02F
    150 mm
    500 mm
    2000 mm
    2.00 mm
    31.532 kg
    Included accessories
    More information
  • STDE 150-60F
    Vertical ladder ST 81-02F
    150 mm
    600 mm
    2000 mm
    2.00 mm
    34.892 kg
    Included accessories
    More information
  • STDE 150-70F
    Vertical ladder ST 81-02F
    150 mm
    700 mm
    2000 mm
    2.00 mm
    38.252 kg
    Included accessories
    More information
  • STDE 150-80F
    Vertical ladder ST 81-02F
    150 mm
    800 mm
    2000 mm
    2.00 mm
    41.612 kg
    Included accessories
    More information
  • STDE 150-90F
    Vertical ladder ST 81-02F
    150 mm
    900 mm
    2000 mm
    2.00 mm
    44.972 kg
    Included accessories
    More information
  • STDE 150-100F
    Vertical ladder ST 81-02F
    150 mm
    1000 mm
    2000 mm
    2.00 mm
    48.332 kg
    Included accessories
    More information
  • STDE 150-110F
    Vertical ladder ST 81-02F
    150 mm
    1100 mm
    2000 mm
    2.00 mm
    55.392 kg
    Included accessories
    More information
  • STDE 150-120F
    Vertical ladder ST 81-02F
    150 mm
    1200 mm
    2000 mm
    2.00 mm
    58.752 kg
    Included accessories
    More information
