STD-A

Cover elevator

The RD cover is placed on top of cover elevator STD-A. Three KLS 8x16 clamps are required to bolt the STD-A to the LGG 60. Three KLS 10x20 are required to bolt the STD-A to the STU 50 and STU 60. If the cover is sendzimir galvanised, three BS 4.2x13GV drilling bolts must be used to attach the cover to the STD-A. Three BLS 3.9x13E tapping bolts are required in combination with the hot-dip galvanised or stainless steel versions. You will need four STD-A for an RD cover 3000 mm long. Please pay careful attention to the number of fastenings required for each particular case. The fastening accessories are not included in the scope of delivery.

Get in touch Download datasheet

Variants

Stahl, band-/sendzimirverzinkt

Article

H

Höhe

L

Länge

t

Materialstärke

G

Gewicht je Lagermengeneinheit
  • STD-A 150S
    Steigetrassen-Deckelerhöhung
    Höhe
    150 mm
    Länge
    1500 mm
    Materialstärke
    1.00 mm
    Gewicht je Lagermengeneinheit
    1.980 kg
    More information
  • STD-A 180S
    Steigetrassen-Deckelerhöhung
    Höhe
    180 mm
    Länge
    1500 mm
    Materialstärke
    1.00 mm
    Gewicht je Lagermengeneinheit
    2.330 kg
    More information

Stahl, stück-/tauchfeuerverzinkt

Article

H

Höhe

L

Länge

t

Materialstärke

G

Gewicht je Lagermengeneinheit
  • STD-A 150F
    Steigetrassen-Deckelerhöhung
    Höhe
    150 mm
    Länge
    1500 mm
    Materialstärke
    1.00 mm
    Gewicht je Lagermengeneinheit
    2.120 kg
    More information
  • STD-A 180F
    Steigetrassen-Deckelerhöhung
    Höhe
    180 mm
    Länge
    1500 mm
    Materialstärke
    1.00 mm
    Gewicht je Lagermengeneinheit
    2.500 kg
    More information

Edelstahl, Werkstoff Nr. 1.4301 (V2A)

Article

H

Höhe

L

Länge

t

Materialstärke

G

Gewicht je Lagermengeneinheit
  • STD-A 150E
    Steigetrassen-Deckelerhöhung
    Höhe
    150 mm
    Länge
    1500 mm
    Materialstärke
    1.00 mm
    Gewicht je Lagermengeneinheit
    2.010 kg
    More information
  • STD-A 180E
    Steigetrassen-Deckelerhöhung
    Höhe
    180 mm
    Länge
    1500 mm
    Materialstärke
    1.00 mm
    Gewicht je Lagermengeneinheit
    2.370 kg
    More information
