Art.-Nr. RIV 60S

Connection plate RIV 60S

Installation cable tray connector, height = 45 mm

Installation cable trays can be connected easily and quickly using the installation cable tray connector RIV 60 and the VB floor connector. The installation cable tray connector RIV 60 is 45 mm high corresponding to the cable tray and 176 mm long. We provide components in various materials and surface finishes to ensure that the corrosion requirements are met for all sorts of applications.

Art.-Nr.
RIV 60S
height
45 mm
length
176 mm
Weight per storage unit
0.123 kg
Get in touch Download datasheet

Variants

steel, continously hot galvanized/Sendzimir process

Article

H

L

W

Included accessories

  • RIV 60S
    Connection plate RIV 60S
    45 mm
    176 mm
    0.123 kg
    Included accessories
    More information

steel, batch/hot-dip galvanized

Article

H

L

W

Included accessories

  • RIV 60F
    Connection plate RIV 60F
    45 mm
    176 mm
    0.130 kg
    Included accessories
    More information

Stainless steel, according to ASTM 304 / BS 304 S 3

Article

H

L

W

Included accessories

Stainless steel, according to ASTM 316 Ti / AISI 316 L, BS 320S17 / BS 316S11

Article

H

L

W

Included accessories
