RIA 60

RIA 60

Installation cable tray tee, height = 60 mm

The installation cable tray branch RIA 60 allows the direction of cable routing to be changed horizontally in the form of a branch. It is inserted between two cable trays and enables another cable tray to be connected at right angles. The cable tray branch is suitable for installation cable trays with sides 60 mm high and is made of sendzimir hot-dip galvanised steel.

Get in touch Download datasheet

Variants

Stahl, band-/sendzimirverzinkt

RIA 60-05S
Installationsrinnenabzweig
Höhe
60 mm
Breite 1
50 mm
Breite 2
50 mm
Länge
164 mm
Gewicht je Lagermengeneinheit
0.913 kg
Included accessories
More information
RIA 60-10-05S
Installationsrinnenabzweig
Höhe
60 mm
Breite 1
100 mm
Breite 2
50 mm
Länge
164 mm
Gewicht je Lagermengeneinheit
0.994 kg
Included accessories
More information
RIA 60-10S
Installationsrinnenabzweig
Höhe
60 mm
Breite 1
100 mm
Breite 2
100 mm
Länge
214 mm
Gewicht je Lagermengeneinheit
1.177 kg
Included accessories
More information
RIA 60-20-10S
Installationsrinnenabzweig
Höhe
60 mm
Breite 1
200 mm
Breite 2
100 mm
Länge
214 mm
Gewicht je Lagermengeneinheit
1.388 kg
Included accessories
More information
RIA 60-20S
Installationsrinnenabzweig
Höhe
60 mm
Breite 1
200 mm
Breite 2
200 mm
Länge
314 mm
Gewicht je Lagermengeneinheit
1.515 kg
Included accessories
More information
RIA 60-30-20S
Installationsrinnenabzweig
Höhe
60 mm
Breite 1
300 mm
Breite 2
200 mm
Länge
314 mm
Gewicht je Lagermengeneinheit
2.027 kg
Included accessories
More information
RIA 60-30S
Installationsrinnenabzweig
Höhe
60 mm
Breite 1
300 mm
Breite 2
300 mm
Länge
414 mm
Gewicht je Lagermengeneinheit
2.453 kg
Included accessories
More information

Stahl, stück-/tauchfeuerverzinkt

RIA 60-05F
Installationsrinnenabzweig
Höhe
60 mm
Breite 1
50 mm
Breite 2
50 mm
Länge
164 mm
Gewicht je Lagermengeneinheit
0.980 kg
Included accessories
More information
RIA 60-10-05F
Installationsrinnenabzweig
Höhe
60 mm
Breite 1
100 mm
Breite 2
50 mm
Länge
164 mm
Gewicht je Lagermengeneinheit
1.067 kg
Included accessories
More information
RIA 60-10F
Installationsrinnenabzweig
Höhe
60 mm
Breite 1
100 mm
Breite 2
100 mm
Länge
214 mm
Gewicht je Lagermengeneinheit
1.262 kg
Included accessories
More information
RIA 60-20-10F
Installationsrinnenabzweig
Höhe
60 mm
Breite 1
200 mm
Breite 2
100 mm
Länge
214 mm
Gewicht je Lagermengeneinheit
1.488 kg
Included accessories
More information
RIA 60-20F
Installationsrinnenabzweig
Höhe
60 mm
Breite 1
200 mm
Breite 2
200 mm
Länge
314 mm
Gewicht je Lagermengeneinheit
1.624 kg
Included accessories
More information
RIA 60-30-20F
Installationsrinnenabzweig
Höhe
60 mm
Breite 1
300 mm
Breite 2
200 mm
Länge
Gewicht je Lagermengeneinheit
2.044 kg
Included accessories
More information
RIA 60-30F
Installationsrinnenabzweig
Höhe
60 mm
Breite 1
300 mm
Breite 2
300 mm
Länge
414 mm
Gewicht je Lagermengeneinheit
2.628 kg
Included accessories
More information

Edelstahl, Werkstoff Nr. 1.4301 (V2A)

RIA 60-05E
Installationsrinnenabzweig
Höhe
60 mm
Breite 1
50 mm
Breite 2
50 mm
Länge
164 mm
Gewicht je Lagermengeneinheit
0.807 kg
Included accessories
More information
RIA 60-10-05E
Installationsrinnenabzweig
Höhe
60 mm
Breite 1
100 mm
Breite 2
50 mm
Länge
164 mm
Gewicht je Lagermengeneinheit
0.888 kg
Included accessories
More information
RIA 60-10E
Installationsrinnenabzweig
Höhe
60 mm
Breite 1
100 mm
Breite 2
100 mm
Länge
214 mm
Gewicht je Lagermengeneinheit
1.054 kg
Included accessories
More information
RIA 60-20-10E
Installationsrinnenabzweig
Höhe
60 mm
Breite 1
200 mm
Breite 2
100 mm
Länge
214 mm
Gewicht je Lagermengeneinheit
1.265 kg
Included accessories
More information
RIA 60-20E
Installationsrinnenabzweig
Höhe
60 mm
Breite 1
200 mm
Breite 2
200 mm
Länge
314 mm
Gewicht je Lagermengeneinheit
1.597 kg
Included accessories
More information
RIA 60-30-20E
Installationsrinnenabzweig
Höhe
60 mm
Breite 1
300 mm
Breite 2
200 mm
Länge
314 mm
Gewicht je Lagermengeneinheit
1.907 kg
Included accessories
More information
RIA 60-30E
Installationsrinnenabzweig
Höhe
60 mm
Breite 1
300 mm
Breite 2
300 mm
Länge
414 mm
Gewicht je Lagermengeneinheit
2.338 kg
Included accessories
More information

Details

Creates horizontal changes of the cable routing direction in the form of a branch
Suitable for installation cable trays
