RIADS

Installation cable tray branch cover, heavy

The installation cable tray branch covers RIADS are suitable for RIA installation cable tray branches and protect them from dirt and moisture. They snap into place and interlock with the side rails. If the covers are to be used outdoors, additional securing brackets to protect against wind are required. The cover is made of sendzimir hot-dip galvanised steel.

Get in touch Download datasheet

Variants

Steel, pre-galvanised/Sendzimir process

Article

B1

width 1

B2

width 2

t

material thickness

G

Weight per storage unit
  • RIADS 05S
    Cable tray branch-piece cover RIADS 05S
    width 1
    50 mm
    width 2
    50 mm
    material thickness
    1.50 mm
    Weight per storage unit
    0.230 kg
    More information
  • RIADS 10S
    Cable tray branch-piece cover RAD 10S
    width 1
    100 mm
    width 2
    100 mm
    material thickness
    1.50 mm
    Weight per storage unit
    0.430 kg
    More information
  • RIADS 20S
    Cable tray branch-piece cover RAD 10S
    width 1
    200 mm
    width 2
    200 mm
    material thickness
    1.50 mm
    Weight per storage unit
    1.000 kg
    More information
  • RIADS 30S
    Cable tray branch-piece cover RAD 10S
    width 1
    300 mm
    width 2
    300 mm
    material thickness
    1.50 mm
    Weight per storage unit
    1.810 kg
    More information
  • RIADS 10-05S
    Cable tray branch-piece cover RAD 10S
    width 1
    100 mm
    width 2
    50 mm
    material thickness
    1.50 mm
    Weight per storage unit
    0.320 kg
    More information
  • RIADS 20-10S
    Cable tray branch-piece cover RAD 10S
    width 1
    200 mm
    width 2
    100 mm
    material thickness
    1.50 mm
    Weight per storage unit
    0.680 kg
    More information
  • RIADS 30-20S
    Cable tray branch-piece cover RAD 10S
    width 1
    300 mm
    width 2
    200 mm
    material thickness
    1.50 mm
    Weight per storage unit
    1.370 kg
    More information

Details

  • Protects the installation cable tray branch RIA against external influences
  • Heavy-duty version
  • Easy assembly without additional tools
