Art.-Nr. LIBD 50E

Wide-span bend cover WPBD 20S

Cable ladder inner bend cover

The cable ladder internal bend covers LIBD are suitable for cable ladder internal bends and protect them from external influences such as dirt and moisture. They are placed on top of the bends. If the covers are to be used outdoors, additional securing brackets to protect against wind are required. We provide components in various materials and surface finishes to ensure that the corrosion requirements are met for all sorts of applications.

Art.-Nr.
LIBD 50E
width
504 mm
material thickness
1.25 mm
Richtungsänderung
horizontal
Winkel
90°
Weight per storage unit
6.420 kg
Get in touch Download datasheet

Variants

steel, continously hot galvanized/Sendzimir process

Article

B

t

direction

W

W

  • LIBD 20S
    Wide-span bend cover WPBD 20S
    204 mm
    0.75 mm
    horizontal
    90°
    1.330 kg
    More information
  • LIBD 30S
    Wide-span bend cover WPBD 20S
    304 mm
    1.00 mm
    horizontal
    90°
    2.750 kg
    More information
  • LIBD 40S
    Wide-span bend cover WPBD 20S
    404 mm
    1.00 mm
    horizontal
    90°
    3.870 kg
    More information
  • LIBD 50S
    Wide-span bend cover WPBD 20S
    504 mm
    1.25 mm
    horizontal
    90°
    6.380 kg
    More information
  • LIBD 60S
    Wide-span bend cover WPBD 20S
    604 mm
    1.25 mm
    horizontal
    90°
    8.090 kg
    More information

steel, batch/hot-dip galvanized

Article

B

t

direction

W

W

  • LIBD 20F
    Wide-span bend cover WPBD 20S
    204 mm
    0.75 mm
    horizontal
    90°
    1.420 kg
    More information
  • LIBD 30F
    Wide-span bend cover WPBD 20S
    304 mm
    1.00 mm
    horizontal
    90°
    2.940 kg
    More information
  • LIBD 40F
    Wide-span bend cover WPBD 20S
    404 mm
    1.00 mm
    horizontal
    90°
    4.140 kg
    More information
  • LIBD 50F
    Wide-span bend cover WPBD 20S
    504 mm
    1.25 mm
    horizontal
    90°
    6.830 kg
    More information
  • LIBD 60F
    Wide-span bend cover WPBD 20S
    604 mm
    1.25 mm
    horizontal
    90°
    8.660 kg
    More information

Stainless steel, according to ASTM 304 / BS 304 S 3

Article

B

t

direction

W

W

  • LIBD 20E
    Wide-span bend cover WPBD 20S
    204 mm
    0.80 mm
    horizontal
    90°
    1.430 kg
    More information
  • LIBD 30E
    Wide-span bend cover WPBD 20S
    304 mm
    1.00 mm
    horizontal
    90°
    2.770 kg
    More information
  • LIBD 40E
    Wide-span bend cover WPBD 20S
    404 mm
    1.00 mm
    horizontal
    90°
    3.900 kg
    More information
  • LIBD 50E
    Wide-span bend cover WPBD 20S
    504 mm
    1.25 mm
    horizontal
    90°
    6.420 kg
    More information
  • LIBD 60E
    Wide-span bend cover WPBD 20S
    604 mm
    1.25 mm
    horizontal
    90°
    8.140 kg
    More information

Details

    Advantages

    • Protects the cable ladder internal bend from external influences
    • Easy assembly without additional tools

Tender texts

Ausschreiben.de

Tender text for this product

Open Link
Heinze.de

Tender text for this product

Open Link

Downloads

  • Price list Building extension 2025

    Valid from February 1st, 2025, updated version from 27/01/2025.

    PDF, 46 MB

    de en

  • Cable ladders - Assembly instructions

    Montageanleitung

    PDF, 2 MB

    de en

  • Cable ladders - Technical information

    Technical information for LGG cable ladders

    PDF, 1 MB

    de en

BIM- and CAD-Data

  • BIM for LGG cable ladders

    BIM for LGG cable ladders

    BIM data

    ZIP, 6 MB

    de en

Included accessories
