KHA 9

40x25 mm profile rail, perforated

The profile rail KHA 9 consists of a C+ profile 39.5 x 25 mm with continuous perforation and a slot width of 18 mm (material thickness = 2.75 mm). It is made of hot-dip galvanised steel and is available in lengths of 200 or 6000 mm.

Get in touch Download datasheet

Variants

Stahl, stück-/tauchfeuerverzinkt

Article

HP

Profilhöhe

BP

Profilbreite

L

Länge

t

Materialstärke

G

Gewicht je Lagermengeneinheit
  • KHA 9-01F
    Profilschiene gelocht 40/25X2,75
    25 mm
    39.5 mm
    100 mm
    2.75 mm
    0.185 kg
    More information
  • KHA 9-02F
    Profilschiene gelocht 40/25X2,75
    25 mm
    39.5 mm
    200 mm
    2.75 mm
    0.370 kg
    More information
  • KHA 9-03F
    Profilschiene gelocht 40/25X2,75
    25 mm
    39.5 mm
    300 mm
    2.75 mm
    0.550 kg
    More information
  • KHA 9-04F
    Profilschiene gelocht 40/25X2,75
    25 mm
    39.5 mm
    400 mm
    2.75 mm
    0.730 kg
    More information
  • KHA 9-05F
    Profilschiene gelocht 40/25X2,75
    25 mm
    39.5 mm
    500 mm
    2.75 mm
    0.910 kg
    More information
  • KHA 9-06F
    Profilschiene gelocht 40/25X2,75
    25 mm
    39.5 mm
    600 mm
    2.75 mm
    1.100 kg
    More information
  • KHA 9-07F
    Profilschiene gelocht 40/25X2,75
    25 mm
    39.5 mm
    700 mm
    2.75 mm
    1.280 kg
    More information
  • KHA 9-08F
    Profilschiene gelocht 40/25X2,75
    25 mm
    39.5 mm
    800 mm
    2.75 mm
    1.460 kg
    More information
  • KHA 9-09F
    Profilschiene gelocht 40/25X2,75
    25 mm
    39.5 mm
    900 mm
    2.75 mm
    1.640 kg
    More information
  • KHA 9-10F
    Profilschiene gelocht 40/25X2,75
    25 mm
    39.5 mm
    1000 mm
    2.75 mm
    1.820 kg
    More information
  • KHA 9-11F
    Profilschiene gelocht 40/25X2,75
    25 mm
    39.5 mm
    1100 mm
    2.75 mm
    2.000 kg
    More information
  • KHA 9-12F
    Profilschiene gelocht 40/25X2,75
    25 mm
    39.5 mm
    1200 mm
    2.75 mm
    2.190 kg
    More information
  • KHA 9-13F
    Profilschiene gelocht 40/25X2,75
    25 mm
    39.5 mm
    1300 mm
    2.75 mm
    2.370 kg
    More information
  • KHA 9-14F
    Profilschiene gelocht 40/25X2,75
    25 mm
    39.5 mm
    1400 mm
    2.75 mm
    2.550 kg
    More information
  • KHA 9-15F
    Profilschiene gelocht 40/25X2,75
    25 mm
    39.5 mm
    1500 mm
    2.75 mm
    2.730 kg
    More information
  • KHA 9-20F
    Profilschiene gelocht 40/25X2,75
    25 mm
    39.5 mm
    2000 mm
    2.75 mm
    3.640 kg
    More information
  • KHA 9-30F
    Profilschiene gelocht 40/25X2,75
    25 mm
    39.5 mm
    3000 mm
    2.75 mm
    5.460 kg
    More information
  • KHA 9-60F
    Profilschiene gelocht 40/25X2,75
    25 mm
    39.5 mm
    6000 mm
    2.75 mm
    10.920 kg
    More information
