KDU 60

Bracket support, heavy, 60x40 mm, maintenance of function

Get in touch Download datasheet

Variants

Steel, hot-dip galvanised

Article

HP

profile height

BP

profile width

L

length

t

material thickness

G

Weight per storage unit
  • KDU 60-02F
    Bracket support KDU 60-02F
    profile height
    40 mm
    profile width
    60 mm
    length
    200 mm
    material thickness
    6.00 mm
    Weight per storage unit
    1.410 kg
    More information
  • KDU 60-03F
    Bracket support KDU 60-03F
    profile height
    40 mm
    profile width
    60 mm
    length
    300 mm
    material thickness
    6.00 mm
    Weight per storage unit
    1.770 kg
    More information
  • KDU 60-04F
    Bracket support KDU 60-04F
    profile height
    40 mm
    profile width
    60 mm
    length
    400 mm
    material thickness
    6.00 mm
    Weight per storage unit
    2.070 kg
    More information
  • KDU 60-05F
    Bracket support KDU 60-05F
    profile height
    40 mm
    profile width
    60 mm
    length
    500 mm
    material thickness
    6.00 mm
    Weight per storage unit
    2.370 kg
    More information
  • KDU 60-06F
    Bracket support KDU 60-06F
    profile height
    40 mm
    profile width
    60 mm
    length
    600 mm
    material thickness
    6.00 mm
    Weight per storage unit
    2.720 kg
    More information
  • KDU 60-07F
    Bracket support KDU 60-07F
    profile height
    40 mm
    profile width
    60 mm
    length
    700 mm
    material thickness
    6.00 mm
    Weight per storage unit
    3.080 kg
    More information
  • KDU 60-08F
    Bracket support KDU 60-08F
    profile height
    40 mm
    profile width
    60 mm
    length
    800 mm
    material thickness
    6.00 mm
    Weight per storage unit
    3.500 kg
    More information
  • KDU 60-09F
    Bracket support KDU 60-09F
    profile height
    40 mm
    profile width
    60 mm
    length
    900 mm
    material thickness
    6.00 mm
    Weight per storage unit
    3.820 kg
    More information
  • KDU 60-10F
    Bracket support KDU 60-10F
    profile height
    40 mm
    profile width
    60 mm
    length
    1000 mm
    material thickness
    6.00 mm
    Weight per storage unit
    4.090 kg
    More information
  • KDU 60-12F
    Bracket support KDU 60-12F
    profile height
    40 mm
    profile width
    60 mm
    length
    1200 mm
    material thickness
    8.00 mm
    Weight per storage unit
    5.200 kg
    More information
  • KDU 60-13F
    Bracket support KDU 60-13F
    profile height
    40 mm
    profile width
    60 mm
    length
    1300 mm
    material thickness
    8.00 mm
    Weight per storage unit
    5.500 kg
    More information
  • KDU 60-14F
    Bracket support KDU 60-14F
    profile height
    40 mm
    profile width
    60 mm
    length
    1400 mm
    material thickness
    8.00 mm
    Weight per storage unit
    5.900 kg
    More information
  • KDU 60-15F
    Bracket support KDU 60-15F
    profile height
    40 mm
    profile width
    60 mm
    length
    1500 mm
    material thickness
    8.00 mm
    Weight per storage unit
    6.300 kg
    More information
