KDU 60

Bracket holder, heavy duty, 60x40 mm for escape route installation

Get in touch Download datasheet

Variants

Steel, hot-dip galvanised

Article

H

height

HP

profile height

B

width

BP

profile width

L

length

t

material thickness

G

Weight per storage unit
  • KDU 60-02F
    Bracket support KDU 60-02F
    height
    40 mm
    profile height
    40 mm
    width
    60 mm
    profile width
    60 mm
    length
    200 mm
    material thickness
    6.00 mm
    Weight per storage unit
    1.410 kg
    More information
  • KDU 60-03F
    Bracket support KDU 60-03F
    height
    40 mm
    profile height
    40 mm
    width
    60 mm
    profile width
    60 mm
    length
    300 mm
    material thickness
    6.00 mm
    Weight per storage unit
    1.770 kg
    More information
  • KDU 60-04F
    Bracket support KDU 60-04F
    height
    40 mm
    profile height
    40 mm
    width
    60 mm
    profile width
    60 mm
    length
    400 mm
    material thickness
    6.00 mm
    Weight per storage unit
    2.070 kg
    More information
  • KDU 60-05F
    Bracket support KDU 60-05F
    height
    40 mm
    profile height
    40 mm
    width
    60 mm
    profile width
    60 mm
    length
    500 mm
    material thickness
    6.00 mm
    Weight per storage unit
    2.370 kg
    More information
  • KDU 60-06F
    Bracket support KDU 60-06F
    height
    40 mm
    profile height
    40 mm
    width
    60 mm
    profile width
    60 mm
    length
    600 mm
    material thickness
    6.00 mm
    Weight per storage unit
    2.720 kg
    More information
  • KDU 60-07F
    Bracket support KDU 60-07F
    height
    40 mm
    profile height
    40 mm
    width
    60 mm
    profile width
    60 mm
    length
    700 mm
    material thickness
    6.00 mm
    Weight per storage unit
    3.080 kg
    More information
  • KDU 60-08F
    Bracket support KDU 60-08F
    height
    40 mm
    profile height
    40 mm
    width
    60 mm
    profile width
    60 mm
    length
    800 mm
    material thickness
    6.00 mm
    Weight per storage unit
    3.500 kg
    More information
  • KDU 60-09F
    Bracket support KDU 60-09F
    height
    40 mm
    profile height
    40 mm
    width
    60 mm
    profile width
    60 mm
    length
    900 mm
    material thickness
    6.00 mm
    Weight per storage unit
    3.820 kg
    More information
  • KDU 60-10F
    Bracket support KDU 60-10F
    height
    40 mm
    profile height
    40 mm
    width
    60 mm
    profile width
    60 mm
    length
    1000 mm
    material thickness
    6.00 mm
    Weight per storage unit
    4.090 kg
    More information
  • KDU 60-11F
    Bracket support KDU 60-11F
    height
    40 mm
    profile height
    40 mm
    width
    60 mm
    profile width
    60 mm
    length
    1100 mm
    material thickness
    8.00 mm
    Weight per storage unit
    4.900 kg
    More information
  • KDU 60-12F
    Bracket support KDU 60-12F
    height
    40 mm
    profile height
    40 mm
    width
    60 mm
    profile width
    60 mm
    length
    1200 mm
    material thickness
    8.00 mm
    Weight per storage unit
    5.200 kg
    More information
  • KDU 60-13F
    Bracket support KDU 60-13F
    height
    40 mm
    profile height
    40 mm
    width
    60 mm
    profile width
    60 mm
    length
    1300 mm
    material thickness
    8.00 mm
    Weight per storage unit
    5.500 kg
    More information
  • KDU 60-14F
    Bracket support KDU 60-14F
    height
    40 mm
    profile height
    40 mm
    width
    60 mm
    profile width
    60 mm
    length
    1400 mm
    material thickness
    8.00 mm
    Weight per storage unit
    5.900 kg
    More information
  • KDU 60-15F
    Bracket support KDU 60-15F
    height
    40 mm
    profile height
    40 mm
    width
    60 mm
    profile width
    60 mm
    length
    1500 mm
    material thickness
    8.00 mm
    Weight per storage unit
    6.300 kg
    More information
  • KDU 60-16F
    Bracket support KDU 60-16F
    height
    40 mm
    profile height
    40 mm
    width
    60 mm
    profile width
    60 mm
    length
    1600 mm
    material thickness
    8.00 mm
    Weight per storage unit
    6.600 kg
    More information
  • KDU 60-17F
    Bracket support KDU 60-17F
    height
    40 mm
    profile height
    40 mm
    width
    60 mm
    profile width
    60 mm
    length
    1700 mm
    material thickness
    8.00 mm
    Weight per storage unit
    7.000 kg
    More information
  • KDU 60-18F
    Bracket support KDU 60-18F
    height
    40 mm
    profile height
    40 mm
    width
    60 mm
    profile width
    60 mm
    length
    1800 mm
    material thickness
    8.00 mm
    Weight per storage unit
    7.300 kg
    More information
  • KDU 60-19F
    Bracket support KDU 60-19F
    height
    40 mm
    profile height
    40 mm
    width
    60 mm
    profile width
    60 mm
    length
    1900 mm
    material thickness
    8.00 mm
    Weight per storage unit
    7.700 kg
    More information
  • KDU 60-20F
    Bracket support KDU 60-20F
    height
    40 mm
    profile height
    40 mm
    width
    60 mm
    profile width
    60 mm
    length
    2000 mm
    material thickness
    8.00 mm
    Weight per storage unit
    7.800 kg
    More information
