KDU 57

Bracket support, 57x30 mm, maintenance of function

Get in touch Download datasheet

Variants

Steel, hot-dip galvanised

Article

HP

profile height

BP

profile width

L

length

t

material thickness

G

Weight per storage unit
  • KDU 57-02F
    Bracket Support KDU 57-02F
    profile height
    30 mm
    profile width
    57 mm
    length
    200 mm
    material thickness
    5.00 mm
    Weight per storage unit
    0.590 kg
    More information
  • KDU 57-03F
    Bracket Support KDU 57-03F
    profile height
    30 mm
    profile width
    57 mm
    length
    300 mm
    material thickness
    5.00 mm
    Weight per storage unit
    0.770 kg
    More information
  • KDU 57-04F
    Bracket Support KDU 57-04F
    profile height
    30 mm
    profile width
    57 mm
    length
    400 mm
    material thickness
    5.00 mm
    Weight per storage unit
    0.950 kg
    More information
  • KDU 57-05F
    Bracket Support KDU 57-05F
    profile height
    30 mm
    profile width
    57 mm
    length
    500 mm
    material thickness
    5.00 mm
    Weight per storage unit
    1.130 kg
    More information
  • KDU 57-06F
    Bracket Support KDU 57-06F
    profile height
    30 mm
    profile width
    57 mm
    length
    600 mm
    material thickness
    5.00 mm
    Weight per storage unit
    1.310 kg
    More information
  • KDU 57-07F
    Bracket Support KDU 57-07F
    profile height
    30 mm
    profile width
    57 mm
    length
    700 mm
    material thickness
    5.00 mm
    Weight per storage unit
    1.490 kg
    More information
  • KDU 57-08F
    Bracket Support KDU 57-08F
    profile height
    30 mm
    profile width
    57 mm
    length
    800 mm
    material thickness
    5.00 mm
    Weight per storage unit
    1.680 kg
    More information
  • KDU 57-09F
    Bracket Support KDU 57-09F
    profile height
    30 mm
    profile width
    57 mm
    length
    900 mm
    material thickness
    5.00 mm
    Weight per storage unit
    1.860 kg
    More information
  • KDU 57-10F
    Bracket Support KDU 57-10F
    profile height
    30 mm
    profile width
    57 mm
    length
    1000 mm
    material thickness
    5.00 mm
    Weight per storage unit
    2.040 kg
    More information
  • KDU 57-11F
    Bracket Support KDU 57-11F
    profile height
    30 mm
    profile width
    57 mm
    length
    1100 mm
    material thickness
    5.00 mm
    Weight per storage unit
    2.220 kg
    More information
  • KDU 57-12F
    Bracket Support KDU 57-12F
    profile height
    30 mm
    profile width
    57 mm
    length
    1200 mm
    material thickness
    5.00 mm
    Weight per storage unit
    2.400 kg
    More information
  • KDU 57-13F
    Bracket Support KDU 57-13F
    profile height
    30 mm
    profile width
    57 mm
    length
    1300 mm
    material thickness
    5.00 mm
    Weight per storage unit
    2.580 kg
    More information
  • KDU 57-14F
    Bracket Support KDU 57-14F
    profile height
    30 mm
    profile width
    57 mm
    length
    1400 mm
    material thickness
    5.00 mm
    Weight per storage unit
    2.770 kg
    More information
  • KDU 57-15F
    Bracket Support KDU 57-15F
    profile height
    30 mm
    profile width
    57 mm
    length
    1500 mm
    material thickness
    5.00 mm
    Weight per storage unit
    2.950 kg
    More information

Tender texts

Ausschreiben.de

Tender text for this product

Open Link
Heinze.de

Tender text for this product

Open Link

Downloads

  • Price list Building extension 2025

    Valid from February 1st, 2025, updated version from 27/01/2025.

    PDF, 46 MB

    de en

  • P-MPA-E-15-019 - KDU57 - Functional maintenance certificate

    General building authority test certificate
    DIN 4102-12
    Cable manufacturers: Dätwyler, Eupen, Leoni Studer, Prysmian, Nexans
    Fire resistance duration: F30; F60; F90
    Functional maintenance classes: E30; E60; F90
    Cable load: ≤ 20 kg/m
    Fastening distance: ≤ 1.5 m
    Cable types: (N)HXH, (N)HXCH, JE-H(St)H,
    Period of validity: 09.10.2026

    PDF, 10 MB

    de
    Download

Included accessories
