KDU 40

Bracket support, 40x30 mm, maintenance of function

Get in touch Download datasheet

Variants

Steel, hot-dip galvanised

Article

HP

profile height

BP

profile width

L

length

t

material thickness

G

Weight per storage unit
  • KDU 40-02F
    Bracket Support KDU 40-02F
    profile height
    30 mm
    profile width
    40 mm
    length
    200 mm
    material thickness
    4.00 mm
    Weight per storage unit
    0.380 kg
    More information
  • KDU 40-03F
    Bracket Support KDU 40-03F
    profile height
    30 mm
    profile width
    40 mm
    length
    300 mm
    material thickness
    4.00 mm
    Weight per storage unit
    0.500 kg
    More information
  • KDU 40-04F
    Bracket Support KDU 40-04F
    profile height
    30 mm
    profile width
    40 mm
    length
    400 mm
    material thickness
    4.00 mm
    Weight per storage unit
    0.620 kg
    More information
  • KDU 40-05F
    Bracket Support KDU 40-05F
    profile height
    30 mm
    profile width
    40 mm
    length
    500 mm
    material thickness
    4.00 mm
    Weight per storage unit
    0.730 kg
    More information
  • KDU 40-06F
    Bracket Support KDU 40-06F
    profile height
    30 mm
    profile width
    40 mm
    length
    600 mm
    material thickness
    4.00 mm
    Weight per storage unit
    0.860 kg
    More information
  • KDU 40-07F
    Bracket Support KDU 40-07F
    profile height
    30 mm
    profile width
    40 mm
    length
    700 mm
    material thickness
    4.00 mm
    Weight per storage unit
    0.980 kg
    More information
  • KDU 40-08F
    Bracket Support KDU 40-08F
    profile height
    30 mm
    profile width
    40 mm
    length
    800 mm
    material thickness
    4.00 mm
    Weight per storage unit
    1.100 kg
    More information
  • KDU 40-09F
    Bracket Support KDU 40-09F
    profile height
    30 mm
    profile width
    40 mm
    length
    900 mm
    material thickness
    4.00 mm
    Weight per storage unit
    1.220 kg
    More information
  • KDU 40-10F
    Bracket Support KDU 40-10F
    profile height
    30 mm
    profile width
    40 mm
    length
    1000 mm
    material thickness
    4.00 mm
    Weight per storage unit
    1.340 kg
    More information
  • KDU 40-11F
    Bracket Support KDU 40-11F
    profile height
    30 mm
    profile width
    40 mm
    length
    1100 mm
    material thickness
    4.00 mm
    Weight per storage unit
    1.460 kg
    More information
  • KDU 40-12F
    Bracket Support KDU 40-12F
    profile height
    30 mm
    profile width
    40 mm
    length
    1200 mm
    material thickness
    4.00 mm
    Weight per storage unit
    1.580 kg
    More information
  • KDU 40-13F
    Bracket Support KDU 40-13F
    profile height
    30 mm
    profile width
    40 mm
    length
    1300 mm
    material thickness
    4.00 mm
    Weight per storage unit
    1.700 kg
    More information
  • KDU 40-14F
    Bracket Support KDU 40-14F
    profile height
    30 mm
    profile width
    40 mm
    length
    1400 mm
    material thickness
    4.00 mm
    Weight per storage unit
    1.820 kg
    More information
  • KDU 40-15F
    Bracket Support KDU 40-15F
    profile height
    30 mm
    profile width
    40 mm
    length
    1500 mm
    material thickness
    4.00 mm
    Weight per storage unit
    1.940 kg
    More information
