JTB-LA

Profiled metal sheet channel, easy to assemble in every installation situation

The profiled metal sheet channel JTB-LA has the general building authority approval (abZ) Z-21.4-2148 and is made of hot-dip galvanized steel (fv).With a stock length of 3000 mm, the channel is available in profile widths of 60 mm and 100 mm; the profile height is 24 mm. The material thickness varies depending on the profile width: 2 mm for 60 mm profile width; 2 mm, 2.5 mm and 3 mm for 100 mm profile width. No additional end anchors are required for individual shortening of the channels The filling consists of polystyrene (PS).

General building approval: Z-21.4-2148
Get in touch Download datasheet

Variants

Steel, hot-dip galvanised

Article

HP

profile height

BP

profile width

L

length

G

Weight per storage unit
  • JTBLA06020-ZMG-3000
    JORDAHL Profiled metal sheet channel
    profile height
    24 mm
    profile width
    60 mm
    length
    3000 mm
    Weight per storage unit
    1.501 kg
    More information
  • JTBLA10020-ZMG-3000
    JORDAHL Profiled metal sheet channel
    profile height
    24 mm
    profile width
    100 mm
    length
    3000 mm
    Weight per storage unit
    2.069 kg
    More information
  • JTBLA10025-ZMG-3000
    JORDAHL Profiled metal sheet channel
    profile height
    24 mm
    profile width
    100 mm
    length
    3000 mm
    Weight per storage unit
    2.520 kg
    More information
  • JTBLA10030-ZMG-3000
    JORDAHL Profiled metal sheet channel
    profile height
    24 mm
    profile width
    100 mm
    length
    3000 mm
    Weight per storage unit
    2.961 kg
    More information

Details

  • General building approval: Z-21.4-2148

Tender texts

Ausschreiben.de

Tender text for this product

Open Link
Heinze.de

Tender text for this product

Open Link

Downloads

  • Installation instructions Profiled Metal Sheet Channels JTB

    Assembly instructions for: JTB-AR, JTB-uni and JTB-LA

    PDF, 356 KB

    de en

  • General building approval Z-21.4-161 Trapezoidal Sheet Fastening Rail JTB

    Zulassung

    PDF, 1,016 KB

    de
    Download

  • General Building Authority Approval for JTB-LA

    AbZ No. Z-21.4-2148, valid until 19th. January, 2028

    PDF, 2 MB

    de
    Download

  • Anchored Trapezoidal Sheet Fastening Rail JTB-LA - Brief Info

    Kurzinformation

    PDF, 353 KB

    de en

BIM- and CAD-Data

  • BIM for Profiled metal sheet channel JTB-LA

    BIM for Profiled metal sheet channel JTB-LA

    BIM data

    ZIP, 369 KB

    de en
  • CAD for Profiled metal sheet channel JTB-LA

    CAD for Profiled metal sheet channel JTB-LA

    CAD data

    ZIP, 1 MB

    de en
