JDA 25

Punching shear reinforcement for transmitting high shear forces in in-situ concrete

The punching shear reinforcements JDA 25 are approved throughout Europe by ETA-13/0136 and have environmental product declaration EPD-JDL-20200260-IBB1-DE. These solutions are suitable for concrete strengths from C20/25 to C50/60. The double-headed anchors are made from reinforcing steel. The strip is made from structural steel in a perforated or unperforated design. The reinforcements are available as standard elements with two or three double-headed anchors per strip. The anchors are 125 to 695 mm long and 10 to 25 mm in diameter. Special solutions are available on request.

Environmental Product Declaration (EPD): EPD-JDL-20200260-IBB1-DE
European Technical Assessment: ETA-13/0136
Get in touch Download datasheet

Variants

Number of anchors: 2 pcs

Article

H

height

B

width

D

diameter

Number of anchors

G

Weight per storage unit
  • JDA25245-0002
    JORDAHL JDA element
    height
    249 mm
    width
    75 mm
    diameter
    25 mm
    Number of anchors
    2 pcs
    Weight per storage unit
    3.133 kg
    More information
  • JDA25255-0002
    JORDAHL JDA element
    height
    259 mm
    width
    75 mm
    diameter
    25 mm
    Number of anchors
    2 pcs
    Weight per storage unit
    3.223 kg
    More information
  • JDA25265-0002
    JORDAHL JDA element
    height
    269 mm
    width
    75 mm
    diameter
    25 mm
    Number of anchors
    2 pcs
    Weight per storage unit
    3.316 kg
    More information
  • JDA25275-0002
    JORDAHL JDA element
    height
    279 mm
    width
    75 mm
    diameter
    25 mm
    Number of anchors
    2 pcs
    Weight per storage unit
    3.406 kg
    More information
  • JDA25285-0002
    JORDAHL JDA element
    height
    289 mm
    width
    75 mm
    diameter
    25 mm
    Number of anchors
    2 pcs
    Weight per storage unit
    3.498 kg
    More information
  • JDA25295-0002
    JORDAHL JDA element
    height
    299 mm
    width
    75 mm
    diameter
    25 mm
    Number of anchors
    2 pcs
    Weight per storage unit
    3.589 kg
    More information
  • JDA25305-0002
    JORDAHL JDA element
    height
    309 mm
    width
    75 mm
    diameter
    25 mm
    Number of anchors
    2 pcs
    Weight per storage unit
    3.681 kg
    More information
  • JDA25315-0002
    JORDAHL JDA element
    height
    319 mm
    width
    75 mm
    diameter
    25 mm
    Number of anchors
    2 pcs
    Weight per storage unit
    3.772 kg
    More information
  • JDA25325-0002
    JORDAHL JDA element
    height
    329 mm
    width
    75 mm
    diameter
    25 mm
    Number of anchors
    2 pcs
    Weight per storage unit
    3.864 kg
    More information
  • JDA25335-0002
    JORDAHL JDA element
    height
    339 mm
    width
    75 mm
    diameter
    25 mm
    Number of anchors
    2 pcs
    Weight per storage unit
    3.954 kg
    More information
  • JDA25345-0002
    JORDAHL JDA element
    height
    349 mm
    width
    75 mm
    diameter
    25 mm
    Number of anchors
    2 pcs
    Weight per storage unit
    4.047 kg
    More information
  • JDA25355-0002
    JORDAHL JDA element
    height
    359 mm
    width
    75 mm
    diameter
    25 mm
    Number of anchors
    2 pcs
    Weight per storage unit
    4.137 kg
    More information
  • JDA25365-0002
    JORDAHL JDA element
    height
    369 mm
    width
    75 mm
    diameter
    25 mm
    Number of anchors
    2 pcs
    Weight per storage unit
    4.230 kg
    More information
  • JDA25375-0002
    JORDAHL JDA element
    height
    379 mm
    width
    75 mm
    diameter
    25 mm
    Number of anchors
    2 pcs
    Weight per storage unit
    4.320 kg
    More information
  • JDA25385-0002
    JORDAHL JDA element
    height
    389 mm
    width
    75 mm
    diameter
    25 mm
    Number of anchors
    2 pcs
    Weight per storage unit
    4.412 kg
    More information
  • JDA25395-0002
    JORDAHL JDA element
    height
    399 mm
    width
    75 mm
    diameter
    25 mm
    Number of anchors
    2 pcs
    Weight per storage unit
    4.503 kg
    More information
  • JDA25405-0002
    JORDAHL JDA element
    height
    409 mm
    width
    75 mm
    diameter
    25 mm
    Number of anchors
    2 pcs
    Weight per storage unit
    4.595 kg
    More information
  • JDA25415-0002
    JORDAHL JDA element
    height
    419 mm
    width
    75 mm
    diameter
    25 mm
    Number of anchors
    2 pcs
    Weight per storage unit
    4.686 kg
    More information
  • JDA25425-0002
    JORDAHL JDA element
    height
    429 mm
    width
    75 mm
    diameter
    25 mm
    Number of anchors
    2 pcs
    Weight per storage unit
    4.778 kg
    More information
  • JDA25435-0002
    JORDAHL JDA element
    height
    439 mm
    width
    75 mm
    diameter
    25 mm
    Number of anchors
    2 pcs
    Weight per storage unit
    4.868 kg
    More information
  • JDA25445-0002
    JORDAHL JDA element
    height
    449 mm
    width
    75 mm
    diameter
    25 mm
    Number of anchors
    2 pcs
    Weight per storage unit
    4.961 kg
    More information
  • JDA25455-0002
    JORDAHL JDA element
    height
    459 mm
    width
    75 mm
    diameter
    25 mm
    Number of anchors
    2 pcs
    Weight per storage unit
    5.051 kg
    More information
  • JDA25465-0002
    JORDAHL JDA element
    height
    469 mm
    width
    75 mm
    diameter
    25 mm
    Number of anchors
    2 pcs
    Weight per storage unit
    5.144 kg
    More information
  • JDA25475-0002
    JORDAHL JDA element
    height
    479 mm
    width
    75 mm
    diameter
    25 mm
    Number of anchors
    2 pcs
    Weight per storage unit
    5.234 kg
    More information
  • JDA25485-0002
    JORDAHL JDA element
    height
    489 mm
    width
    75 mm
    diameter
    25 mm
    Number of anchors
    2 pcs
    Weight per storage unit
    5.326 kg
    More information
  • JDA25495-0002
    JORDAHL JDA element
    height
    499 mm
    width
    75 mm
    diameter
    25 mm
    Number of anchors
    2 pcs
    Weight per storage unit
    5.417 kg
    More information
  • JDA25505-0002
    JORDAHL JDA element
    height
    509 mm
    width
    75 mm
    diameter
    25 mm
    Number of anchors
    2 pcs
    Weight per storage unit
    5.509 kg
    More information
  • JDA25515-0002
    JORDAHL JDA element
    height
    519 mm
    width
    75 mm
    diameter
    25 mm
    Number of anchors
    2 pcs
    Weight per storage unit
    5.600 kg
    More information
  • JDA25525-0002
    JORDAHL JDA element
    height
    529 mm
    width
    75 mm
    diameter
    25 mm
    Number of anchors
    2 pcs
    Weight per storage unit
    5.692 kg
    More information
  • JDA25535-0002
    JORDAHL JDA element
    height
    539 mm
    width
    75 mm
    diameter
    25 mm
    Number of anchors
    2 pcs
    Weight per storage unit
    5.782 kg
    More information
  • JDA25545-0002
    JORDAHL JDA element
    height
    549 mm
    width
    75 mm
    diameter
    25 mm
    Number of anchors
    2 pcs
    Weight per storage unit
    5.875 kg
    More information
  • JDA25555-0002
    JORDAHL JDA element
    height
    559 mm
    width
    75 mm
    diameter
    25 mm
    Number of anchors
    2 pcs
    Weight per storage unit
    5.965 kg
    More information
  • JDA25565-0002
    JORDAHL JDA element
    height
    569 mm
    width
    75 mm
    diameter
    25 mm
    Number of anchors
    2 pcs
    Weight per storage unit
    6.058 kg
    More information
  • JDA25575-0002
    JORDAHL JDA element
    height
    579 mm
    width
    75 mm
    diameter
    25 mm
    Number of anchors
    2 pcs
    Weight per storage unit
    6.148 kg
    More information
  • JDA25585-0002
    JORDAHL JDA element
    height
    589 mm
    width
    75 mm
    diameter
    25 mm
    Number of anchors
    2 pcs
    Weight per storage unit
    6.240 kg
    More information
  • JDA25595-0002
    JORDAHL JDA element
    height
    599 mm
    width
    75 mm
    diameter
    25 mm
    Number of anchors
    2 pcs
    Weight per storage unit
    6.331 kg
    More information
  • JDA25605-0002
    JORDAHL JDA element
    height
    609 mm
    width
    75 mm
    diameter
    25 mm
    Number of anchors
    2 pcs
    Weight per storage unit
    6.423 kg
    More information
  • JDA25615-0002
    JORDAHL JDA element
    height
    619 mm
    width
    75 mm
    diameter
    25 mm
    Number of anchors
    2 pcs
    Weight per storage unit
    6.514 kg
    More information
  • JDA25625-0002
    JORDAHL JDA element
    height
    629 mm
    width
    75 mm
    diameter
    25 mm
    Number of anchors
    2 pcs
    Weight per storage unit
    6.606 kg
    More information
  • JDA25635-0002
    JORDAHL JDA element
    height
    639 mm
    width
    75 mm
    diameter
    25 mm
    Number of anchors
    2 pcs
    Weight per storage unit
    6.696 kg
    More information
  • JDA25645-0002
    JORDAHL JDA element
    height
    649 mm
    width
    75 mm
    diameter
    25 mm
    Number of anchors
    2 pcs
    Weight per storage unit
    6.789 kg
    More information
  • JDA25655-0002
    JORDAHL JDA element
    height
    659 mm
    width
    75 mm
    diameter
    25 mm
    Number of anchors
    2 pcs
    Weight per storage unit
    6.879 kg
    More information
  • JDA25665-0002
    JORDAHL JDA element
    height
    669 mm
    width
    75 mm
    diameter
    25 mm
    Number of anchors
    2 pcs
    Weight per storage unit
    6.972 kg
    More information
  • JDA25675-0002
    JORDAHL JDA element
    height
    679 mm
    width
    75 mm
    diameter
    25 mm
    Number of anchors
    2 pcs
    Weight per storage unit
    7.062 kg
    More information
  • JDA25685-0002
    JORDAHL JDA element
    height
    689 mm
    width
    75 mm
    diameter
    25 mm
    Number of anchors
    2 pcs
    Weight per storage unit
    7.154 kg
    More information
  • JDA25695-0002
    JORDAHL JDA element
    height
    699 mm
    width
    75 mm
    diameter
    25 mm
    Number of anchors
    2 pcs
    Weight per storage unit
    7.245 kg
    More information

Number of anchors: 3 pcs

Article

H

height

B

width

D

diameter

Number of anchors

G

Weight per storage unit
  • JDA25245-0003
    JORDAHL JDA element
    height
    249 mm
    width
    75 mm
    diameter
    25 mm
    Number of anchors
    3 pcs
    Weight per storage unit
    6.292 kg
    More information
  • JDA25255-0003
    JORDAHL JDA element
    height
    259 mm
    width
    75 mm
    diameter
    25 mm
    Number of anchors
    3 pcs
    Weight per storage unit
    4.835 kg
    More information
  • JDA25265-0003
    JORDAHL JDA element
    height
    269 mm
    width
    75 mm
    diameter
    25 mm
    Number of anchors
    3 pcs
    Weight per storage unit
    4.973 kg
    More information
  • JDA25275-0003
    JORDAHL JDA element
    height
    279 mm
    width
    75 mm
    diameter
    25 mm
    Number of anchors
    3 pcs
    Weight per storage unit
    5.109 kg
    More information
  • JDA25285-0003
    JORDAHL JDA element
    height
    289 mm
    width
    75 mm
    diameter
    25 mm
    Number of anchors
    3 pcs
    Weight per storage unit
    5.248 kg
    More information
  • JDA25295-0003
    JORDAHL JDA element
    height
    299 mm
    width
    75 mm
    diameter
    25 mm
    Number of anchors
    3 pcs
    Weight per storage unit
    5.383 kg
    More information
  • JDA25305-0003
    JORDAHL JDA element
    height
    309 mm
    width
    75 mm
    diameter
    25 mm
    Number of anchors
    3 pcs
    Weight per storage unit
    5.522 kg
    More information
  • JDA25315-0003
    JORDAHL JDA element
    height
    319 mm
    width
    75 mm
    diameter
    25 mm
    Number of anchors
    3 pcs
    Weight per storage unit
    5.657 kg
    More information
  • JDA25325-0003
    JORDAHL JDA element
    height
    329 mm
    width
    75 mm
    diameter
    25 mm
    Number of anchors
    3 pcs
    Weight per storage unit
    5.796 kg
    More information
  • JDA25335-0003
    JORDAHL JDA element
    height
    339 mm
    width
    75 mm
    diameter
    25 mm
    Number of anchors
    3 pcs
    Weight per storage unit
    5.932 kg
    More information
  • JDA25345-0003
    JORDAHL JDA element
    height
    349 mm
    width
    75 mm
    diameter
    25 mm
    Number of anchors
    3 pcs
    Weight per storage unit
    6.070 kg
    More information
  • JDA25355-0003
    JORDAHL JDA element
    height
    359 mm
    width
    75 mm
    diameter
    25 mm
    Number of anchors
    3 pcs
    Weight per storage unit
    6.206 kg
    More information
  • JDA25365-0003
    JORDAHL JDA element
    height
    369 mm
    width
    75 mm
    diameter
    25 mm
    Number of anchors
    3 pcs
    Weight per storage unit
    6.344 kg
    More information
  • JDA25375-0003
    JORDAHL JDA element
    height
    379 mm
    width
    75 mm
    diameter
    25 mm
    Number of anchors
    3 pcs
    Weight per storage unit
    6.480 kg
    More information
  • JDA25385-0003
    JORDAHL JDA element
    height
    389 mm
    width
    75 mm
    diameter
    25 mm
    Number of anchors
    3 pcs
    Weight per storage unit
    6.619 kg
    More information
  • JDA25395-0003
    JORDAHL JDA element
    height
    399 mm
    width
    75 mm
    diameter
    25 mm
    Number of anchors
    3 pcs
    Weight per storage unit
    6.754 kg
    More information
  • JDA25405-0003
    JORDAHL JDA element
    height
    409 mm
    width
    75 mm
    diameter
    25 mm
    Number of anchors
    3 pcs
    Weight per storage unit
    6.893 kg
    More information
  • JDA25415-0003
    JORDAHL JDA element
    height
    419 mm
    width
    75 mm
    diameter
    25 mm
    Number of anchors
    3 pcs
    Weight per storage unit
    7.028 kg
    More information
  • JDA25425-0003
    JORDAHL JDA element
    height
    429 mm
    width
    75 mm
    diameter
    25 mm
    Number of anchors
    3 pcs
    Weight per storage unit
    7.167 kg
    More information
  • JDA25435-0003
    JORDAHL JDA element
    height
    439 mm
    width
    75 mm
    diameter
    25 mm
    Number of anchors
    3 pcs
    Weight per storage unit
    7.303 kg
    More information
  • JDA25445-0003
    JORDAHL JDA element
    height
    449 mm
    width
    75 mm
    diameter
    25 mm
    Number of anchors
    3 pcs
    Weight per storage unit
    7.441 kg
    More information
  • JDA25455-0003
    JORDAHL JDA element
    height
    459 mm
    width
    75 mm
    diameter
    25 mm
    Number of anchors
    3 pcs
    Weight per storage unit
    7.577 kg
    More information
  • JDA25465-0003
    JORDAHL JDA element
    height
    469 mm
    width
    75 mm
    diameter
    25 mm
    Number of anchors
    3 pcs
    Weight per storage unit
    7.715 kg
    More information
  • JDA25475-0003
    JORDAHL JDA element
    height
    479 mm
    width
    75 mm
    diameter
    25 mm
    Number of anchors
    3 pcs
    Weight per storage unit
    7.851 kg
    More information
  • JDA25485-0003
    JORDAHL JDA element
    height
    489 mm
    width
    75 mm
    diameter
    25 mm
    Number of anchors
    3 pcs
    Weight per storage unit
    7.990 kg
    More information
  • JDA25495-0003
    JORDAHL JDA element
    height
    499 mm
    width
    75 mm
    diameter
    25 mm
    Number of anchors
    3 pcs
    Weight per storage unit
    8.125 kg
    More information
  • JDA25505-0003
    JORDAHL JDA element
    height
    509 mm
    width
    75 mm
    diameter
    25 mm
    Number of anchors
    3 pcs
    Weight per storage unit
    8.264 kg
    More information
  • JDA25515-0003
    JORDAHL JDA element
    height
    519 mm
    width
    75 mm
    diameter
    25 mm
    Number of anchors
    3 pcs
    Weight per storage unit
    8.399 kg
    More information
  • JDA25525-0003
    JORDAHL JDA element
    height
    529 mm
    width
    75 mm
    diameter
    25 mm
    Number of anchors
    3 pcs
    Weight per storage unit
    8.538 kg
    More information
  • JDA25535-0003
    JORDAHL JDA element
    height
    539 mm
    width
    75 mm
    diameter
    25 mm
    Number of anchors
    3 pcs
    Weight per storage unit
    8.674 kg
    More information
  • JDA25545-0003
    JORDAHL JDA element
    height
    549 mm
    width
    75 mm
    diameter
    25 mm
    Number of anchors
    3 pcs
    Weight per storage unit
    8.812 kg
    More information
  • JDA25555-0003
    JORDAHL JDA element
    height
    559 mm
    width
    75 mm
    diameter
    25 mm
    Number of anchors
    3 pcs
    Weight per storage unit
    8.948 kg
    More information
  • JDA25565-0003
    JORDAHL JDA element
    height
    569 mm
    width
    75 mm
    diameter
    25 mm
    Number of anchors
    3 pcs
    Weight per storage unit
    9.086 kg
    More information
  • JDA25575-0003
    JORDAHL JDA element
    height
    579 mm
    width
    75 mm
    diameter
    25 mm
    Number of anchors
    3 pcs
    Weight per storage unit
    9.222 kg
    More information
  • JDA25585-0003
    JORDAHL JDA element
    height
    589 mm
    width
    75 mm
    diameter
    25 mm
    Number of anchors
    3 pcs
    Weight per storage unit
    9.361 kg
    More information
  • JDA25595-0003
    JORDAHL JDA element
    height
    599 mm
    width
    75 mm
    diameter
    25 mm
    Number of anchors
    3 pcs
    Weight per storage unit
    9.496 kg
    More information
  • JDA25605-0003
    JORDAHL JDA element
    height
    609 mm
    width
    75 mm
    diameter
    25 mm
    Number of anchors
    3 pcs
    Weight per storage unit
    9.635 kg
    More information
  • JDA25615-0003
    JORDAHL JDA element
    height
    619 mm
    width
    75 mm
    diameter
    25 mm
    Number of anchors
    3 pcs
    Weight per storage unit
    9.770 kg
    More information
  • JDA25625-0003
    JORDAHL JDA element
    height
    629 mm
    width
    75 mm
    diameter
    25 mm
    Number of anchors
    3 pcs
    Weight per storage unit
    9.909 kg
    More information
  • JDA25635-0003
    JORDAHL JDA element
    height
    639 mm
    width
    75 mm
    diameter
    25 mm
    Number of anchors
    3 pcs
    Weight per storage unit
    10.045 kg
    More information
  • JDA25645-0003
    JORDAHL JDA element
    height
    649 mm
    width
    75 mm
    diameter
    25 mm
    Number of anchors
    3 pcs
    Weight per storage unit
    10.183 kg
    More information
  • JDA25655-0003
    JORDAHL JDA element
    height
    659 mm
    width
    75 mm
    diameter
    25 mm
    Number of anchors
    3 pcs
    Weight per storage unit
    10.319 kg
    More information
  • JDA25665-0003
    JORDAHL JDA element
    height
    669 mm
    width
    75 mm
    diameter
    25 mm
    Number of anchors
    3 pcs
    Weight per storage unit
    10.457 kg
    More information
  • JDA25675-0003
    JORDAHL JDA element
    height
    679 mm
    width
    75 mm
    diameter
    25 mm
    Number of anchors
    3 pcs
    Weight per storage unit
    10.593 kg
    More information
  • JDA25685-0003
    JORDAHL JDA element
    height
    689 mm
    width
    75 mm
    diameter
    25 mm
    Number of anchors
    3 pcs
    Weight per storage unit
    10.732 kg
    More information
  • JDA25695-0003
    JORDAHL JDA element
    height
    699 mm
    width
    75 mm
    diameter
    25 mm
    Number of anchors
    3 pcs
    Weight per storage unit
    10.867 kg
    More information

Number of anchors: 4 pcs

Article

H

height

B

width

D

diameter

Number of anchors

G

Weight per storage unit
  • JDA25245-0004
    JORDAHL JDA element
    height
    249 mm
    width
    75 mm
    diameter
    25 mm
    Number of anchors
    4 pcs
    Weight per storage unit
    6.266 kg
    More information
  • JDA25255-0004
    JORDAHL JDA element
    height
    259 mm
    width
    75 mm
    diameter
    25 mm
    Number of anchors
    4 pcs
    Weight per storage unit
    6.446 kg
    More information
  • JDA25265-0004
    JORDAHL JDA element
    height
    269 mm
    width
    75 mm
    diameter
    25 mm
    Number of anchors
    4 pcs
    Weight per storage unit
    6.631 kg
    More information
  • JDA25275-0004
    JORDAHL JDA element
    height
    279 mm
    width
    75 mm
    diameter
    25 mm
    Number of anchors
    4 pcs
    Weight per storage unit
    6.812 kg
    More information
  • JDA25285-0004
    JORDAHL JDA element
    height
    289 mm
    width
    75 mm
    diameter
    25 mm
    Number of anchors
    4 pcs
    Weight per storage unit
    6.997 kg
    More information
  • JDA25295-0004
    JORDAHL JDA element
    height
    299 mm
    width
    75 mm
    diameter
    25 mm
    Number of anchors
    4 pcs
    Weight per storage unit
    7.178 kg
    More information
  • JDA25305-0004
    JORDAHL JDA element
    height
    309 mm
    width
    75 mm
    diameter
    25 mm
    Number of anchors
    4 pcs
    Weight per storage unit
    7.362 kg
    More information
  • JDA25315-0004
    JORDAHL JDA element
    height
    319 mm
    width
    75 mm
    diameter
    25 mm
    Number of anchors
    4 pcs
    Weight per storage unit
    7.543 kg
    More information
  • JDA25325-0004
    JORDAHL JDA element
    height
    329 mm
    width
    75 mm
    diameter
    25 mm
    Number of anchors
    4 pcs
    Weight per storage unit
    7.728 kg
    More information
  • JDA25335-0004
    JORDAHL JDA element
    height
    339 mm
    width
    75 mm
    diameter
    25 mm
    Number of anchors
    4 pcs
    Weight per storage unit
    7.909 kg
    More information
  • JDA25345-0004
    JORDAHL JDA element
    height
    349 mm
    width
    75 mm
    diameter
    25 mm
    Number of anchors
    4 pcs
    Weight per storage unit
    8.094 kg
    More information
  • JDA25355-0004
    JORDAHL JDA element
    height
    359 mm
    width
    75 mm
    diameter
    25 mm
    Number of anchors
    4 pcs
    Weight per storage unit
    8.274 kg
    More information
  • JDA25365-0004
    JORDAHL JDA element
    height
    369 mm
    width
    75 mm
    diameter
    25 mm
    Number of anchors
    4 pcs
    Weight per storage unit
    8.459 kg
    More information
  • JDA25375-0004
    JORDAHL JDA element
    height
    379 mm
    width
    75 mm
    diameter
    25 mm
    Number of anchors
    4 pcs
    Weight per storage unit
    8.640 kg
    More information
  • JDA25385-0004
    JORDAHL JDA element
    height
    389 mm
    width
    75 mm
    diameter
    25 mm
    Number of anchors
    4 pcs
    Weight per storage unit
    8.825 kg
    More information
  • JDA25395-0004
    JORDAHL JDA element
    height
    399 mm
    width
    75 mm
    diameter
    25 mm
    Number of anchors
    4 pcs
    Weight per storage unit
    9.006 kg
    More information
  • JDA25405-0004
    JORDAHL JDA element
    height
    409 mm
    width
    75 mm
    diameter
    25 mm
    Number of anchors
    4 pcs
    Weight per storage unit
    9.190 kg
    More information
  • JDA25415-0004
    JORDAHL JDA element
    height
    419 mm
    width
    75 mm
    diameter
    25 mm
    Number of anchors
    4 pcs
    Weight per storage unit
    9.371 kg
    More information
  • JDA25425-0004
    JORDAHL JDA element
    height
    429 mm
    width
    75 mm
    diameter
    25 mm
    Number of anchors
    4 pcs
    Weight per storage unit
    9.556 kg
    More information
  • JDA25435-0004
    JORDAHL JDA element
    height
    439 mm
    width
    75 mm
    diameter
    25 mm
    Number of anchors
    4 pcs
    Weight per storage unit
    9.737 kg
    More information
  • JDA25445-0004
    JORDAHL JDA element
    height
    449 mm
    width
    75 mm
    diameter
    25 mm
    Number of anchors
    4 pcs
    Weight per storage unit
    9.922 kg
    More information
  • JDA25455-0004
    JORDAHL JDA element
    height
    459 mm
    width
    75 mm
    diameter
    25 mm
    Number of anchors
    4 pcs
    Weight per storage unit
    10.102 kg
    More information
  • JDA25465-0004
    JORDAHL JDA element
    height
    469 mm
    width
    75 mm
    diameter
    25 mm
    Number of anchors
    4 pcs
    Weight per storage unit
    10.287 kg
    More information
  • JDA25475-0004
    JORDAHL JDA element
    height
    479 mm
    width
    75 mm
    diameter
    25 mm
    Number of anchors
    4 pcs
    Weight per storage unit
    10.468 kg
    More information
  • JDA25485-0004
    JORDAHL JDA element
    height
    489 mm
    width
    75 mm
    diameter
    25 mm
    Number of anchors
    4 pcs
    Weight per storage unit
    10.653 kg
    More information
  • JDA25495-0004
    JORDAHL JDA element
    height
    499 mm
    width
    75 mm
    diameter
    25 mm
    Number of anchors
    4 pcs
    Weight per storage unit
    10.834 kg
    More information
  • JDA25505-0004
    JORDAHL JDA element
    height
    509 mm
    width
    75 mm
    diameter
    25 mm
    Number of anchors
    4 pcs
    Weight per storage unit
    11.018 kg
    More information
  • JDA25515-0004
    JORDAHL JDA element
    height
    519 mm
    width
    75 mm
    diameter
    25 mm
    Number of anchors
    4 pcs
    Weight per storage unit
    11.199 kg
    More information
  • JDA25525-0004
    JORDAHL JDA element
    height
    529 mm
    width
    75 mm
    diameter
    25 mm
    Number of anchors
    4 pcs
    Weight per storage unit
    11.384 kg
    More information
  • JDA25535-0004
    JORDAHL JDA element
    height
    539 mm
    width
    75 mm
    diameter
    25 mm
    Number of anchors
    4 pcs
    Weight per storage unit
    11.565 kg
    More information
  • JDA25545-0004
    JORDAHL JDA element
    height
    549 mm
    width
    75 mm
    diameter
    25 mm
    Number of anchors
    4 pcs
    Weight per storage unit
    11.750 kg
    More information
  • JDA25555-0004
    JORDAHL JDA element
    height
    559 mm
    width
    75 mm
    diameter
    25 mm
    Number of anchors
    4 pcs
    Weight per storage unit
    11.930 kg
    More information
  • JDA25565-0004
    JORDAHL JDA element
    height
    569 mm
    width
    75 mm
    diameter
    25 mm
    Number of anchors
    4 pcs
    Weight per storage unit
    12.115 kg
    More information
  • JDA25575-0004
    JORDAHL JDA element
    height
    579 mm
    width
    75 mm
    diameter
    25 mm
    Number of anchors
    4 pcs
    Weight per storage unit
    12.296 kg
    More information
  • JDA25585-0004
    JORDAHL JDA element
    height
    589 mm
    width
    75 mm
    diameter
    25 mm
    Number of anchors
    4 pcs
    Weight per storage unit
    12.481 kg
    More information
  • JDA25595-0004
    JORDAHL JDA element
    height
    599 mm
    width
    75 mm
    diameter
    25 mm
    Number of anchors
    4 pcs
    Weight per storage unit
    12.662 kg
    More information
  • JDA25605-0004
    JORDAHL JDA element
    height
    609 mm
    width
    75 mm
    diameter
    25 mm
    Number of anchors
    4 pcs
    Weight per storage unit
    12.846 kg
    More information
  • JDA25615-0004
    JORDAHL JDA element
    height
    619 mm
    width
    75 mm
    diameter
    25 mm
    Number of anchors
    4 pcs
    Weight per storage unit
    13.027 kg
    More information
  • JDA25625-0004
    JORDAHL JDA element
    height
    629 mm
    width
    75 mm
    diameter
    25 mm
    Number of anchors
    4 pcs
    Weight per storage unit
    13.212 kg
    More information
  • JDA25635-0004
    JORDAHL JDA element
    height
    639 mm
    width
    75 mm
    diameter
    25 mm
    Number of anchors
    4 pcs
    Weight per storage unit
    13.393 kg
    More information
  • JDA25645-0004
    JORDAHL JDA element
    height
    649 mm
    width
    75 mm
    diameter
    25 mm
    Number of anchors
    4 pcs
    Weight per storage unit
    13.578 kg
    More information
  • JDA25655-0004
    JORDAHL JDA element
    height
    659 mm
    width
    75 mm
    diameter
    25 mm
    Number of anchors
    4 pcs
    Weight per storage unit
    13.758 kg
    More information
  • JDA25665-0004
    JORDAHL JDA element
    height
    669 mm
    width
    75 mm
    diameter
    25 mm
    Number of anchors
    4 pcs
    Weight per storage unit
    13.943 kg
    More information
  • JDA25675-0004
    JORDAHL JDA element
    height
    679 mm
    width
    75 mm
    diameter
    25 mm
    Number of anchors
    4 pcs
    Weight per storage unit
    14.124 kg
    More information
  • JDA25685-0004
    JORDAHL JDA element
    height
    689 mm
    width
    75 mm
    diameter
    25 mm
    Number of anchors
    4 pcs
    Weight per storage unit
    14.309 kg
    More information
  • JDA25695-0004
    JORDAHL JDA element
    height
    699 mm
    width
    75 mm
    diameter
    25 mm
    Number of anchors
    4 pcs
    Weight per storage unit
    14.490 kg
    More information

Number of anchors: 5 pcs

Article

H

height

B

width

D

diameter

Number of anchors

G

Weight per storage unit
  • JDA25245-0005
    JORDAHL JDA element
    height
    249 mm
    width
    75 mm
    diameter
    25 mm
    Number of anchors
    5 pcs
    Weight per storage unit
    7.832 kg
    More information
  • JDA25255-0005
    JORDAHL JDA element
    height
    259 mm
    width
    75 mm
    diameter
    25 mm
    Number of anchors
    5 pcs
    Weight per storage unit
    8.058 kg
    More information
  • JDA25265-0005
    JORDAHL JDA element
    height
    269 mm
    width
    75 mm
    diameter
    25 mm
    Number of anchors
    5 pcs
    Weight per storage unit
    8.289 kg
    More information
  • JDA25275-0005
    JORDAHL JDA element
    height
    279 mm
    width
    75 mm
    diameter
    25 mm
    Number of anchors
    5 pcs
    Weight per storage unit
    8.515 kg
    More information
  • JDA25285-0005
    JORDAHL JDA element
    height
    289 mm
    width
    75 mm
    diameter
    25 mm
    Number of anchors
    5 pcs
    Weight per storage unit
    8.746 kg
    More information
  • JDA25295-0005
    JORDAHL JDA element
    height
    299 mm
    width
    75 mm
    diameter
    25 mm
    Number of anchors
    5 pcs
    Weight per storage unit
    8.972 kg
    More information
  • JDA25305-0005
    JORDAHL JDA element
    height
    309 mm
    width
    75 mm
    diameter
    25 mm
    Number of anchors
    5 pcs
    Weight per storage unit
    9.203 kg
    More information
  • JDA25315-0005
    JORDAHL JDA element
    height
    319 mm
    width
    75 mm
    diameter
    25 mm
    Number of anchors
    5 pcs
    Weight per storage unit
    9.429 kg
    More information
  • JDA25325-0005
    JORDAHL JDA element
    height
    329 mm
    width
    75 mm
    diameter
    25 mm
    Number of anchors
    5 pcs
    Weight per storage unit
    9.660 kg
    More information
  • JDA25335-0005
    JORDAHL JDA element
    height
    339 mm
    width
    75 mm
    diameter
    25 mm
    Number of anchors
    5 pcs
    Weight per storage unit
    9.886 kg
    More information
  • JDA25345-0005
    JORDAHL JDA element
    height
    349 mm
    width
    75 mm
    diameter
    25 mm
    Number of anchors
    5 pcs
    Weight per storage unit
    10.117 kg
    More information
  • JDA25355-0005
    JORDAHL JDA element
    height
    359 mm
    width
    75 mm
    diameter
    25 mm
    Number of anchors
    5 pcs
    Weight per storage unit
    10.343 kg
    More information
  • JDA25365-0005
    JORDAHL JDA element
    height
    369 mm
    width
    75 mm
    diameter
    25 mm
    Number of anchors
    5 pcs
    Weight per storage unit
    10.574 kg
    More information
  • JDA25375-0005
    JORDAHL JDA element
    height
    379 mm
    width
    75 mm
    diameter
    25 mm
    Number of anchors
    5 pcs
    Weight per storage unit
    10.800 kg
    More information
  • JDA25385-0005
    JORDAHL JDA element
    height
    389 mm
    width
    75 mm
    diameter
    25 mm
    Number of anchors
    5 pcs
    Weight per storage unit
    11.031 kg
    More information
  • JDA25395-0005
    JORDAHL JDA element
    height
    399 mm
    width
    75 mm
    diameter
    25 mm
    Number of anchors
    5 pcs
    Weight per storage unit
    11.257 kg
    More information
  • JDA25405-0005
    JORDAHL JDA element
    height
    409 mm
    width
    75 mm
    diameter
    25 mm
    Number of anchors
    5 pcs
    Weight per storage unit
    11.488 kg
    More information
  • JDA25415-0005
    JORDAHL JDA element
    height
    419 mm
    width
    75 mm
    diameter
    25 mm
    Number of anchors
    5 pcs
    Weight per storage unit
    11.714 kg
    More information
  • JDA25425-0005
    JORDAHL JDA element
    height
    429 mm
    width
    75 mm
    diameter
    25 mm
    Number of anchors
    5 pcs
    Weight per storage unit
    11.945 kg
    More information
  • JDA25435-0005
    JORDAHL JDA element
    height
    439 mm
    width
    75 mm
    diameter
    25 mm
    Number of anchors
    5 pcs
    Weight per storage unit
    12.171 kg
    More information
  • JDA25445-0005
    JORDAHL JDA element
    height
    449 mm
    width
    75 mm
    diameter
    25 mm
    Number of anchors
    5 pcs
    Weight per storage unit
    12.402 kg
    More information
  • JDA25455-0005
    JORDAHL JDA element
    height
    459 mm
    width
    75 mm
    diameter
    25 mm
    Number of anchors
    5 pcs
    Weight per storage unit
    12.628 kg
    More information
  • JDA25465-0005
    JORDAHL JDA element
    height
    469 mm
    width
    75 mm
    diameter
    25 mm
    Number of anchors
    5 pcs
    Weight per storage unit
    12.859 kg
    More information
  • JDA25475-0005
    JORDAHL JDA element
    height
    479 mm
    width
    75 mm
    diameter
    25 mm
    Number of anchors
    5 pcs
    Weight per storage unit
    13.085 kg
    More information
  • JDA25485-0005
    JORDAHL JDA element
    height
    489 mm
    width
    75 mm
    diameter
    25 mm
    Number of anchors
    5 pcs
    Weight per storage unit
    13.316 kg
    More information
  • JDA25495-0005
    JORDAHL JDA element
    height
    499 mm
    width
    75 mm
    diameter
    25 mm
    Number of anchors
    5 pcs
    Weight per storage unit
    13.542 kg
    More information
  • JDA25505-0005
    JORDAHL JDA element
    height
    509 mm
    width
    75 mm
    diameter
    25 mm
    Number of anchors
    5 pcs
    Weight per storage unit
    13.773 kg
    More information
  • JDA25515-0005
    JORDAHL JDA element
    height
    519 mm
    width
    75 mm
    diameter
    25 mm
    Number of anchors
    5 pcs
    Weight per storage unit
    13.999 kg
    More information
  • JDA25525-0005
    JORDAHL JDA element
    height
    529 mm
    width
    75 mm
    diameter
    25 mm
    Number of anchors
    5 pcs
    Weight per storage unit
    14.230 kg
    More information
  • JDA25535-0005
    JORDAHL JDA element
    height
    539 mm
    width
    75 mm
    diameter
    25 mm
    Number of anchors
    5 pcs
    Weight per storage unit
    14.456 kg
    More information
  • JDA25545-0005
    JORDAHL JDA element
    height
    549 mm
    width
    75 mm
    diameter
    25 mm
    Number of anchors
    5 pcs
    Weight per storage unit
    14.687 kg
    More information
  • JDA25555-0005
    JORDAHL JDA element
    height
    559 mm
    width
    75 mm
    diameter
    25 mm
    Number of anchors
    5 pcs
    Weight per storage unit
    14.913 kg
    More information
  • JDA25565-0005
    JORDAHL JDA element
    height
    569 mm
    width
    75 mm
    diameter
    25 mm
    Number of anchors
    5 pcs
    Weight per storage unit
    15.144 kg
    More information
  • JDA25575-0005
    JORDAHL JDA element
    height
    579 mm
    width
    75 mm
    diameter
    25 mm
    Number of anchors
    5 pcs
    Weight per storage unit
    15.370 kg
    More information
  • JDA25585-0005
    JORDAHL JDA element
    height
    589 mm
    width
    75 mm
    diameter
    25 mm
    Number of anchors
    5 pcs
    Weight per storage unit
    15.601 kg
    More information
  • JDA25595-0005
    JORDAHL JDA element
    height
    599 mm
    width
    75 mm
    diameter
    25 mm
    Number of anchors
    5 pcs
    Weight per storage unit
    15.827 kg
    More information
  • JDA25605-0005
    JORDAHL JDA element
    height
    609 mm
    width
    75 mm
    diameter
    25 mm
    Number of anchors
    5 pcs
    Weight per storage unit
    16.058 kg
    More information
  • JDA25615-0005
    JORDAHL JDA element
    height
    619 mm
    width
    75 mm
    diameter
    25 mm
    Number of anchors
    5 pcs
    Weight per storage unit
    16.284 kg
    More information
  • JDA25625-0005
    JORDAHL JDA element
    height
    629 mm
    width
    75 mm
    diameter
    25 mm
    Number of anchors
    5 pcs
    Weight per storage unit
    16.515 kg
    More information
  • JDA25635-0005
    JORDAHL JDA element
    height
    639 mm
    width
    75 mm
    diameter
    25 mm
    Number of anchors
    5 pcs
    Weight per storage unit
    16.741 kg
    More information
  • JDA25645-0005
    JORDAHL JDA element
    height
    649 mm
    width
    75 mm
    diameter
    25 mm
    Number of anchors
    5 pcs
    Weight per storage unit
    16.972 kg
    More information
  • JDA25655-0005
    JORDAHL JDA element
    height
    659 mm
    width
    75 mm
    diameter
    25 mm
    Number of anchors
    5 pcs
    Weight per storage unit
    17.198 kg
    More information
  • JDA25665-0005
    JORDAHL JDA element
    height
    669 mm
    width
    75 mm
    diameter
    25 mm
    Number of anchors
    5 pcs
    Weight per storage unit
    17.429 kg
    More information
  • JDA25675-0005
    JORDAHL JDA element
    height
    679 mm
    width
    75 mm
    diameter
    25 mm
    Number of anchors
    5 pcs
    Weight per storage unit
    17.655 kg
    More information
  • JDA25685-0005
    JORDAHL JDA element
    height
    689 mm
    width
    75 mm
    diameter
    25 mm
    Number of anchors
    5 pcs
    Weight per storage unit
    17.886 kg
    More information
  • JDA25695-0005
    JORDAHL JDA element
    height
    699 mm
    width
    75 mm
    diameter
    25 mm
    Number of anchors
    5 pcs
    Weight per storage unit
    18.112 kg
    More information

Number of anchors: 6 pcs

Article

H

height

B

width

D

diameter

Number of anchors

G

Weight per storage unit
  • JDA25245-0006
    JORDAHL JDA element
    height
    249 mm
    width
    75 mm
    diameter
    25 mm
    Number of anchors
    6 pcs
    Weight per storage unit
    9.398 kg
    More information
  • JDA25255-0006
    JORDAHL JDA element
    height
    259 mm
    width
    75 mm
    diameter
    25 mm
    Number of anchors
    6 pcs
    Weight per storage unit
    9.670 kg
    More information
  • JDA25265-0006
    JORDAHL JDA element
    height
    269 mm
    width
    75 mm
    diameter
    25 mm
    Number of anchors
    6 pcs
    Weight per storage unit
    9.947 kg
    More information
  • JDA25275-0006
    JORDAHL JDA element
    height
    279 mm
    width
    75 mm
    diameter
    25 mm
    Number of anchors
    6 pcs
    Weight per storage unit
    10.218 kg
    More information
  • JDA25285-0006
    JORDAHL JDA element
    height
    289 mm
    width
    75 mm
    diameter
    25 mm
    Number of anchors
    6 pcs
    Weight per storage unit
    10.495 kg
    More information
  • JDA25295-0006
    JORDAHL JDA element
    height
    299 mm
    width
    75 mm
    diameter
    25 mm
    Number of anchors
    6 pcs
    Weight per storage unit
    10.766 kg
    More information
  • JDA25305-0006
    JORDAHL JDA element
    height
    309 mm
    width
    75 mm
    diameter
    25 mm
    Number of anchors
    6 pcs
    Weight per storage unit
    11.044 kg
    More information
  • JDA25315-0006
    JORDAHL JDA element
    height
    319 mm
    width
    75 mm
    diameter
    25 mm
    Number of anchors
    6 pcs
    Weight per storage unit
    11.315 kg
    More information
  • JDA25325-0006
    JORDAHL JDA element
    height
    329 mm
    width
    75 mm
    diameter
    25 mm
    Number of anchors
    6 pcs
    Weight per storage unit
    11.592 kg
    More information
  • JDA25335-0006
    JORDAHL JDA element
    height
    339 mm
    width
    75 mm
    diameter
    25 mm
    Number of anchors
    6 pcs
    Weight per storage unit
    11.863 kg
    More information
  • JDA25345-0006
    JORDAHL JDA element
    height
    349 mm
    width
    75 mm
    diameter
    25 mm
    Number of anchors
    6 pcs
    Weight per storage unit
    12.140 kg
    More information
  • JDA25355-0006
    JORDAHL JDA element
    height
    359 mm
    width
    75 mm
    diameter
    25 mm
    Number of anchors
    6 pcs
    Weight per storage unit
    12.412 kg
    More information
  • JDA25365-0006
    JORDAHL JDA element
    height
    369 mm
    width
    75 mm
    diameter
    25 mm
    Number of anchors
    6 pcs
    Weight per storage unit
    12.689 kg
    More information
  • JDA25375-0006
    JORDAHL JDA element
    height
    379 mm
    width
    75 mm
    diameter
    25 mm
    Number of anchors
    6 pcs
    Weight per storage unit
    12.960 kg
    More information
  • JDA25385-0006
    JORDAHL JDA element
    height
    389 mm
    width
    75 mm
    diameter
    25 mm
    Number of anchors
    6 pcs
    Weight per storage unit
    13.237 kg
    More information
  • JDA25395-0006
    JORDAHL JDA element
    height
    399 mm
    width
    75 mm
    diameter
    25 mm
    Number of anchors
    6 pcs
    Weight per storage unit
    13.508 kg
    More information
  • JDA25405-0006
    JORDAHL JDA element
    height
    409 mm
    width
    75 mm
    diameter
    25 mm
    Number of anchors
    6 pcs
    Weight per storage unit
    13.786 kg
    More information
  • JDA25415-0006
    JORDAHL JDA element
    height
    419 mm
    width
    75 mm
    diameter
    25 mm
    Number of anchors
    6 pcs
    Weight per storage unit
    14.057 kg
    More information
  • JDA25425-0006
    JORDAHL JDA element
    height
    429 mm
    width
    75 mm
    diameter
    25 mm
    Number of anchors
    6 pcs
    Weight per storage unit
    14.334 kg
    More information
  • JDA25435-0006
    JORDAHL JDA element
    height
    439 mm
    width
    75 mm
    diameter
    25 mm
    Number of anchors
    6 pcs
    Weight per storage unit
    14.605 kg
    More information
  • JDA25445-0006
    JORDAHL JDA element
    height
    449 mm
    width
    75 mm
    diameter
    25 mm
    Number of anchors
    6 pcs
    Weight per storage unit
    14.882 kg
    More information
  • JDA25455-0006
    JORDAHL JDA element
    height
    459 mm
    width
    75 mm
    diameter
    25 mm
    Number of anchors
    6 pcs
    Weight per storage unit
    15.154 kg
    More information
  • JDA25465-0006
    JORDAHL JDA element
    height
    469 mm
    width
    75 mm
    diameter
    25 mm
    Number of anchors
    6 pcs
    Weight per storage unit
    15.431 kg
    More information
  • JDA25475-0006
    JORDAHL JDA element
    height
    479 mm
    width
    75 mm
    diameter
    25 mm
    Number of anchors
    6 pcs
    Weight per storage unit
    15.702 kg
    More information
  • JDA25485-0006
    JORDAHL JDA element
    height
    489 mm
    width
    75 mm
    diameter
    25 mm
    Number of anchors
    6 pcs
    Weight per storage unit
    15.979 kg
    More information
  • JDA25495-0006
    JORDAHL JDA element
    height
    499 mm
    width
    75 mm
    diameter
    25 mm
    Number of anchors
    6 pcs
    Weight per storage unit
    16.250 kg
    More information
  • JDA25505-0006
    JORDAHL JDA element
    height
    509 mm
    width
    75 mm
    diameter
    25 mm
    Number of anchors
    6 pcs
    Weight per storage unit
    16.528 kg
    More information
  • JDA25515-0006
    JORDAHL JDA element
    height
    519 mm
    width
    75 mm
    diameter
    25 mm
    Number of anchors
    6 pcs
    Weight per storage unit
    16.799 kg
    More information
  • JDA25525-0006
    JORDAHL JDA element
    height
    529 mm
    width
    75 mm
    diameter
    25 mm
    Number of anchors
    6 pcs
    Weight per storage unit
    17.076 kg
    More information
  • JDA25535-0006
    JORDAHL JDA element
    height
    539 mm
    width
    75 mm
    diameter
    25 mm
    Number of anchors
    6 pcs
    Weight per storage unit
    17.347 kg
    More information
  • JDA25545-0006
    JORDAHL JDA element
    height
    549 mm
    width
    75 mm
    diameter
    25 mm
    Number of anchors
    6 pcs
    Weight per storage unit
    17.624 kg
    More information
  • JDA25555-0006
    JORDAHL JDA element
    height
    559 mm
    width
    75 mm
    diameter
    25 mm
    Number of anchors
    6 pcs
    Weight per storage unit
    17.896 kg
    More information
  • JDA25565-0006
    JORDAHL JDA element
    height
    569 mm
    width
    75 mm
    diameter
    25 mm
    Number of anchors
    6 pcs
    Weight per storage unit
    18.173 kg
    More information
  • JDA25575-0006
    JORDAHL JDA element
    height
    579 mm
    width
    75 mm
    diameter
    25 mm
    Number of anchors
    6 pcs
    Weight per storage unit
    18.444 kg
    More information
  • JDA25585-0006
    JORDAHL JDA element
    height
    589 mm
    width
    75 mm
    diameter
    25 mm
    Number of anchors
    6 pcs
    Weight per storage unit
    18.721 kg
    More information
  • JDA25595-0006
    JORDAHL JDA element
    height
    599 mm
    width
    75 mm
    diameter
    25 mm
    Number of anchors
    6 pcs
    Weight per storage unit
    18.992 kg
    More information
  • JDA25605-0006
    JORDAHL JDA element
    height
    609 mm
    width
    75 mm
    diameter
    25 mm
    Number of anchors
    6 pcs
    Weight per storage unit
    19.270 kg
    More information
  • JDA25615-0006
    JORDAHL JDA element
    height
    619 mm
    width
    75 mm
    diameter
    25 mm
    Number of anchors
    6 pcs
    Weight per storage unit
    19.541 kg
    More information
  • JDA25625-0006
    JORDAHL JDA element
    height
    629 mm
    width
    75 mm
    diameter
    25 mm
    Number of anchors
    6 pcs
    Weight per storage unit
    19.818 kg
    More information
  • JDA25635-0006
    JORDAHL JDA element
    height
    639 mm
    width
    75 mm
    diameter
    25 mm
    Number of anchors
    6 pcs
    Weight per storage unit
    20.089 kg
    More information
  • JDA25645-0006
    JORDAHL JDA element
    height
    649 mm
    width
    75 mm
    diameter
    25 mm
    Number of anchors
    6 pcs
    Weight per storage unit
    20.366 kg
    More information
  • JDA25655-0006
    JORDAHL JDA element
    height
    659 mm
    width
    75 mm
    diameter
    25 mm
    Number of anchors
    6 pcs
    Weight per storage unit
    20.638 kg
    More information
  • JDA25665-0006
    JORDAHL JDA element
    height
    669 mm
    width
    75 mm
    diameter
    25 mm
    Number of anchors
    6 pcs
    Weight per storage unit
    20.915 kg
    More information
  • JDA25675-0006
    JORDAHL JDA element
    height
    679 mm
    width
    75 mm
    diameter
    25 mm
    Number of anchors
    6 pcs
    Weight per storage unit
    21.186 kg
    More information
  • JDA25685-0006
    JORDAHL JDA element
    height
    689 mm
    width
    75 mm
    diameter
    25 mm
    Number of anchors
    6 pcs
    Weight per storage unit
    21.463 kg
    More information
  • JDA25695-0006
    JORDAHL JDA element
    height
    699 mm
    width
    75 mm
    diameter
    25 mm
    Number of anchors
    6 pcs
    Weight per storage unit
    21.734 kg
    More information

Details

  • Environmental Product Declaration (EPD): EPD-JDL-20200260-IBB1-DE
  • European Technical Assessment: ETA-13/0136

Tender texts

Ausschreiben.de

Tender text for this product

Open Link
Heinze.de

Tender text for this product

Open Link

Downloads

  • Price list 2025 Shell construction / facade

    Valid from February 1, 2025

    PDF, 18 MB

    de en

  • Punching shear reinforcement JDA - Technical information

    Technische Information

    PDF, 4 MB

    de en

  • ETA-13/0136 Punching Shear Reinforcement JDA

    Zulassung

    PDF, 1 MB

    de en
  • EXPERT Software JDA Punching shear reinforcement

    EXPERT Software JDA Punching shear reinforcement

    ZIP, 73 MB

    de en

  • EPD Environmental Product Declaration JDA

    Erklärung

    PDF, 2 MB

    de en

  • Declaration of Performance JDA

    Erklärung

    PDF, 78 KB

    de en

  • Installation Instructions Punching Shear Reinforcement JDA

    Montageanleitung

    PDF, 184 KB

    de en

BIM- and CAD-Data

  • BIM Data Punching Shear Reinforcement JDA

    BIM Data Punching Shear Reinforcement JDA

    Systemansicht

    ZIP, 6 MB

    de en
  • BIM for Installation parts punching shear reinforcement JDA (ALLPLAN)

    BIM for Installation parts punching shear reinforcement JDA (ALLPLAN)

    SUPPARTS© Installation parts

    ZIP, 2 MB

    de en

Included accessories

Services: From planning to utilisation

We support you at every step of your construction project. With high-quality products including dimensioning software for optimum planning. If the standard product is not suitable for your project, our manufacturers will configure a product that is precisely tailored to your needs.

Consulting, planning, design

Customised solutions
