FRSV

Round-head bolt with short square, DIN 603

The round-head bolt with a short square FRSV (in line with DIN 603) is used in numerous applications, including the assembly of fixed and floating bearings for cable ladders and trays, the attachment of storm safety brackets or the assembly of mesh cable tray connectors. The round-head bolt is available in lengths from 12 to 20 mm and with threads M6 and M10. We provide components in various materials and surface finishes to ensure that various corrosion protection requirements for different areas of application are met.

Get in touch Download datasheet

Variants

steel, batch/hot-dip galvanized

Article

L

D

d

Ø

W

  • FRSV 10X20F
    Cup square neck bolt FRSV 10X20F
    20 mm
    24 mm
    2.5 mm
    10 mm
    0.022 kg
    More information

steel, galvanic zinc plated

Article

L

D

d

Ø

W

  • FRSV 10X20
    Cup square neck bolt FRSV 10X20
    20 mm
    24 mm
    2.5 mm
    10 mm
    0.022 kg
    More information
  • FRSV 6X12
    Cup square neck bolt FRSV 6X12
    12 mm
    16 mm
    1.5 mm
    6 mm
    0.005 kg
    More information
  • FRSV 6X16
    Cup square neck bolt FRSV 6X16
    16 mm
    16 mm
    1.5 mm
    6 mm
    0.006 kg
    More information
  • FRSV 8X16
    Cup square neck bolt FRSV 8X16
    16 mm
    20 mm
    2 mm
    8 mm
    0.012 kg
    More information

Stainless steel, according to ASTM 304 / BS 304 S 3

Article

L

D

d

Ø

W

  • FRSV 10X20E
    Cup square neck bolt FRSV 10X20E
    20 mm
    24 mm
    2.5 mm
    10 mm
    0.022 kg
    More information
  • FRSV 6X12E
    Cup square neck bolt FRSV 6X12E
    12 mm
    16 mm
    1.5 mm
    6 mm
    0.005 kg
    More information
  • FRSV 6X16E
    Cup square neck bolt FRSV 6X16E
    16 mm
    16 mm
    1.5 mm
    6 mm
    0.006 kg
    More information
  • FRSV 8X16E
    Cup square neck bolt FRSV 8X16E
    16 mm
    20 mm
    2 mm
    8 mm
    0.012 kg
    More information

Stainless steel, according to ASTM 316 Ti / AISI 316 L, BS 320S17 / BS 316S11

Article

L

D

d

Ø

W

  • FRSV 10X20E4
    Cup square neck bolt FRSV 10X20E4
    20 mm
    24 mm
    2.5 mm
    10 mm
    0.024 kg
    More information
  • FRSV 6X12E4
    Truss-head bolts
    12 mm
    16 mm
    1.5 mm
    6 mm
    0.006 kg
    More information
  • FRSV 6X16E4
    cup square neck bolt FRSV 6x16E4
    16 mm
    16 mm
    1.5 mm
    6 mm
    0.006 kg
    More information
  • FRSV 8X16E4
    Cup square neck bolt FRSV 8X16E
    16 mm
    20 mm
    2.0 mm
    8 mm
    0.012 kg
    More information
